Easy Operation Water Bottle Blowing Machine 4 Cavity Stretch Blow Moulding Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Features: | Automatic | Application: | Bottle|water Bottle |
|---|---|---|---|
| Plastic Processed: | PET|plastic | Voltage: | 220V|380V |
| Volume: | 2L | Name: | Bottle Blowing Machine |
| Material: | Stainless Steel | ||
| High Light: | bottle blow molding machine,automatic blow moulding machine |
||
Easy Operation Water Bottle Blowing Machine 4 Cavity Stretch Blow Moulding Machine
Quick Detail:
- Condition: New
- Application: Bottle
- Plastic Processed: PET
- Blow Moulding Type: Stretch Blow Moulding
- Automatic: Yes
- Model Number: CM-8Y
- Name:Name:Bottle Blowing Machine
Description:
1,Infrared lamps adoped in the pre-heater ensures PET preforms being heated evenly.
2,Mechanical-double-arm calmping ensures mould being tightly closed under hight pressure and high temperature.
3,Pneumatic system consists of two parts. pneumatic acting part and bottle blowing part in order to meet different requirements for both acting and blowing. It provides sufficient steady high pressure to blowing. It provides sufficient steady high pressure to bloww large irregular shape bottles.
4,Equipped with silencer and oiling system to lubricate the mechanical pars of the machine.
5,Operated step-by-step and in semi-auto maode.
6,Wide-mouth jar and hot-fill bottles can also be made.
Applications:
4 Cavity Semi Automatic Blowing Machine Manufacturers Water Bottle Blowing Machine is suitable for producing PET plastic containers and bottles in all shapes.
Specifications:
|
TYPE
|
ITEM
|
MEASUREMENT
|
Combined type
|
Standard type
|
|
END PRODUCT
|
Material
|
/
|
PET/PP/PE/PC
|
PET/PP/PE/PC
|
|
Volume
|
L
|
0.05-2.5(2-cavity)
3-6(1-cavity)
|
0.05-2.5 (2-cavity)
3-6 (1-cavity)
|
|
|
Theoretical output
|
Pcs/h
|
0.05-2.5L/1700
3-6L/800
|
0.05-2.5L/850
3-6L/400
|
|
|
Max.length
|
mm
|
360
|
360
|
|
|
max.diameter
|
mm
|
180
|
180
|
|
|
MOULD PLATE
|
Max.mould plate
dimension(L×H) |
mm
|
420×500
|
420×500
|
|
Max.mould thickness
|
mm
|
160-240
|
160-240
|
|
|
Clamping force
|
KN
|
90
|
90
|
|
|
Mould opening stroke (adjustable)
|
mm
|
200
|
200
|
|
|
AUXILARY
|
High pressure
Compressor M3/Mpa
|
KW
|
>=0.70/3.0×1set 22
|
>=0.7/3.0×2sets 22
|
|
Precision air filters
|
M3/Mpa
|
>=1.0/3.0×2pcs
|
>=1.0/3.0×2pcs
|
|
|
MAIN MACHINE ELECTRICITY
|
Power
|
KW
|
12
|
12
|
|
Voltae/Frequency
|
V/HZ
|
220-380/50-60
|
||
|
MACHINE SIZE
AND WEIGHT |
Main body dimension(L×W×H)
|
M
|
1.45×0.6×1.75
|
1.45×0.6×1.75
|
|
Main body weight
|
T
|
0.6
|
0.6
|
|
|
Conveyor dimension(L*W*H)
|
M
|
1.40×0.62×1.25
|
1.40×0.62×1.25
|
|
|
Conveyor weight
|
T
|
0.22
|
0.22
|
|
|
SAFTY
|
Auto-emergency alarm
|
SAFETY INTER-LOCKING DEVICE
|
||
Competitive Advantage:
*Reasonable design, full automaticlly control, save power and labor.
*Feeding system carries the preforms by robot arms automatically.
*Infrared oven adopts the quartz lamp to heat the PET tube.
*Fully automatic process with low investment, high efficiency,quick and safe operation, easy for maintenance.
*We have perfect service after sales .
*Adopting high quality components.
4 Cavity Semi Automatic Blowing Machine Manufacturers Water Bottle Blowing Machine
Download for more details:
Full Automatic Bottle blowing machine.pdf
