220V Auto Stretch Blow Molding Machine /Bottle Blowing Machine For PET Bottles PET Blower
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Features: | Automatic | Application: | Bottle|water Bottle |
|---|---|---|---|
| Plastic Processed: | PET|plastic | Product Name: | Automatic Stretch Blow Molding Machine Blowing Machine For PET Bottles PET Blower |
| Voltage: | 220V | Volume: | 2L |
| Name: | Bottle Blowing Machine | Material: | SUS 304 316 |
| High Light: | blow moulding machine,bottle blow molding machine |
||
220V Auto Stretch Blow Molding Machine /Bottle Blowing Machine For PET Bottles PET Blower
Quick Detail:
- Condition: New
- Application: Bottle
- Plastic Processed: PET
- Blow Moulding Type: Stretch Blow Moulding
- Automatic: Yes
- Model Number: CM-8Y
- Name:Bottle Blowing Machine
Description:
1,Infrared lamps adoped in the pre-heater ensures PET preforms being heated evenly.
2,Mechanical-double-arm calmping ensures mould being tightly closed under hight pressure and high temperature.
3,Pneumatic system consists of two parts. pneumatic acting part and bottle blowing part in order to meet different requirements for both acting and blowing. It provides sufficient steady high pressure to blowing. It provides sufficient steady high pressure to bloww large irregular shape bottles.
4,Equipped with silencer and oiling system to lubricate the mechanical pars of the machine.
5,Operated step-by-step and in semi-auto maode.
6,Wide-mouth jar and hot-fill bottles can also be made.
Applications:
CM-8Y Semiautomatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 0.1L to 2L.
Parameters:
|
TYPE
|
ITEM
|
MEASUREMENT
|
HZ-880 Combined type
|
HZ-880 Standard type
|
|
END PRODUCT
|
Material
|
/
|
PET/PP/PE/PC
|
PET/PP/PE/PC
|
|
Volume
|
L
|
0.05-2.5(2-cavity)
3-6(1-cavity)
|
0.05-2.5 (2-cavity)
3-6 (1-cavity)
|
|
|
Theoretical output
|
Pcs/h
|
0.05-2.5L/1700
3-6L/800
|
0.05-2.5L/850
3-6L/400
|
|
|
Max.length
|
mm
|
360
|
360
|
|
|
max.diameter
|
mm
|
180
|
180
|
|
|
MOULD PLATE
|
Max.mould plate
dimension(L×H) |
mm
|
420×500
|
420×500
|
|
Max.mould thickness
|
mm
|
160-240
|
160-240
|
|
|
Clamping force
|
KN
|
90
|
90
|
|
|
Mould opening stroke (adjustable)
|
mm
|
200
|
200
|
|
|
AUXILARY
|
High pressure
Compressor M3/Mpa
|
KW
|
>=0.70/3.0×1set 22
|
>=0.7/3.0×2sets 22
|
|
Precision air filters
|
M3/Mpa
|
>=1.0/3.0×2pcs
|
>=1.0/3.0×2pcs
|
|
|
MAIN MACHINE ELECTRICITY
|
Power
|
KW
|
12
|
12
|
|
Voltae/Frequency
|
V/HZ
|
220-380/50-60
|
||
|
MACHINE SIZE
AND WEIGHT |
Main body dimension(L×W×H)
|
M
|
1.45×0.6×1.75
|
1.45×0.6×1.75
|
|
Main body weight
|
T
|
0.6
|
0.6
|
|
|
Conveyor dimension(L*W*H)
|
M
|
1.40×0.62×1.25
|
1.40×0.62×1.25
|
|
|
Conveyor weight
|
T
|
0.22
|
0.22
|
|
|
SAFTY
|
Auto-emergency alarm
|
SAFETY INTER-LOCKING DEVICE
|
||
Competitive Advantage:
- Save Cost
- Stable Quality
- Save Place
Automatic Stretch Blow Molding Machine Blowing Machine for PET Bottles PET Blower
Download for more details:
Automatic Shrink Packing Machine.pdf
