18.9L Semi - Automatic PET Bottle Blowing Machine Plastic Blow Moulding Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Product: | 18.9L Semi-automatic Plastic Blow Moulding Machine PET Blow Molding Machine | Bottle Size: | 3Gallon 5Gallon |
|---|---|---|---|
| Name: | Bottle Blowing Machine | Product Material: | PET |
| Power: | 40KW | Volume: | 8L-25L |
| Material: | Stainless Steel | ||
| High Light: | automatic blow moulding machine,bottle blow molding machine |
||
18.9L Semi - Automatic PET Bottle Blowing Machine Plastic Blow Moulding Machine
Introduction:
5 Gallons PET Bottle Blowing Machine
is especially used to produce 3 gallon and 5 gallon bottles and is widely used to produce any shape of plastic from PET with neck finishes from 15mm-200mm.
Name:Bottle Blowing Machine
Function:
1.Perfect function with economic investment.
2.Small size and compact construction with no space waste.
3.Easy to operate and maintain,operation by one person.
4.Saving power and uneasy to worn out.Adopting new double crank four bars to lock mould,the cross fixed.Providing high pressure blowing system.
5.We can provide various preform and cap moulds from 3-5 gallon to meet customers' requirements.
Technical parameter:
| Model | CM-1Y Semi-automatic 5 Gallon PET Bottle Blowing Machine | |
| Container | Product material | PET |
| Volume | 8L-25L(3-5Gallon) | |
| Theoretical output | 90-180PCS/H | |
| Preform length | 15mm-460mm | |
| Preform inner diameter | 5mm-200mm | |
| Moulding | Max.mould plate Dimenstion(L x W) | 420x500mm |
| Max.mould thickness | 400mm | |
| Clamping force | 330KN | |
| Mould opening stroke | 380mm | |
| Machine size and weight | Main machine (L x W x H) | 218*77*196cm |
| Main machine weight | 1000Kg | |
| Heater (L x W x H) | 237*68*165cm | |
| Heater weight | 380Kg | |
| Power |
40kw |
|
Download for more details:
Semi Automatic Bottle blowing machine.pdf
18.9L Semi-automatic Plastic Blow Moulding Machine PET Blow Molding Machine
