100BPH Bottle Blowing Machine 5 Gallon Barrel Stretch Blow Moulding Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Features: | Automatic | Application: | Bottle|water Bottle |
|---|---|---|---|
| Plastic Processed: | PET|plastic | Voltage: | 220V|380V |
| Volume: | 2L | Name: | Bottle Blowing Machine |
| Material: | Stainless Steel | ||
| High Light: | bottle blow molding machine,automatic blow moulding machine |
||
100BPH Bottle Blowing Machine 5 Gallon Barrel Stretch Blow Moulding Machine
Quick Detail:
- Condition: New
- Application: Bottle
- Plastic Processed: PET
- Blow Moulding Type: Stretch Blow Moulding
- Automatic: Yes
- Model Number: BX-D1
- Name:Bottle Blowing Machine
Description:
1.Perfect function with economic investment.
2.Small size and compact construction with no space waste.
3.Easy to operate and maintain,operation by one person.
4.Saving power and uneasy to worn out.Adopting new double crank four bars to lock mould,the cross fixed. Providing high pressure blowing system.
5.We can provide performs and cap moulds for 5 gallon and 3 gallon bottle to meet customer's requirements.
Applications:
5 Gallon Barrel Stretch Blow Moulding Machine Bottle Blowing Machine Price 100BPH is suitable for producing PET plastic containers and bottles in all shapes.
Specifications:
Technical parameter:
|
ITEM
|
UNIT
|
BX-D1
|
|
Cavity
|
pcs
|
1
|
|
Min.product capacity
|
L
|
10
|
|
Max.product capacity
|
L
|
25
|
|
Min.inner neck diameter
|
mm
|
55
|
|
Max.inner neck diameter
|
mm
|
150
|
|
Max.product diameter
|
mm
|
300
|
|
Max.product height
|
mm
|
470
|
|
Max.mould thickness
|
mm
|
200-350
|
|
Mould opening stroke(Adjustable)
|
mm
|
350
|
|
Theoretical output
|
bph
|
60-90
|
|
Operating pressure
|
Mpa
|
0.7-1.0
|
|
Blowing pressure
|
Mpa
|
1-3
|
|
Heater power
|
kw
|
28.8
|
|
Machine weight
|
kg
|
1300
|
|
Heater weight
|
kg
|
350
|
|
Machine dimension(L*W*H)
|
m
|
2.2×0.8×1.9
|
|
Heater dimension(L*W*H)
|
m
|
2.4×0.7×1.7
|
Competitive Advantage:
*Reasonable design, full automaticlly control, save power and labor.
*Feeding system carries the preforms by robot arms automatically.
*Infrared oven adopts the quartz lamp to heat the PET tube.
*Fully automatic process with low investment, high efficiency,quick and safe operation, easy for maintenance.
*We have perfect service after sales .
*Adopting high quality components.
100BPH Bottle Blowing Machine 5 Gallon Barrel Stretch Blow Moulding Machine
Download for more details:
Full Automatic Bottle blowing machine.pdf
