Fully Automatic PET Bottle Blowing Machine 4000 BPH 48 KW High Efficiency

Large Image : Fully Automatic PET Bottle Blowing Machine 4000 BPH 48 KW High Efficiency Get Best Price

Product Details:

Place of Origin:	Zhangjiagang China
Brand Name:	Renda
Certification:	ISO,CE
Model Number:	CM-A4

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiabled
Packaging Details:	Wooden case
Delivery Time:	30 days
Payment Terms:	T/T, L/C
Supply Ability:	30 pcs/month

Contact Now

Detailed Product Description

Features:	Automatic	Total Power:	48KW
Application:	Bottle\|water Bottle	Plastic Processed:	PET\|plastic
Product Name:	Full Automatic PET Blow Moulding Machine Injection Blow Molding Machine 6000BPH	Voltage:	380V
Name:	Bottle Blowing Machine	Material:	SUS 304 316
High Light:	blow moulding machine , bottle blow molding machine

Fully Automatic PET Bottle Blowing Machine 4000 BPH 48 KW High Efficiency

Quick Detail:

Condition: New
Application: Bottle
Plastic Processed: PET
Blow Moulding Type: Stretch Blow Moulding
Automatic: Yes
Model Number: CM-A4
Name:Bottle Blowing Machine

Description:

1. Stable performance with advanced PLC.
2. Conveying preforms automatically with conveyor.
3. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.
4. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.
5. High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.
6. No contamination and low noise with the air cylinder to drive the action instead of the oil pump.
7. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.

Applications:

Full Automatic PET Blow Moulding Machine Injection Blow Molding Machine 6000BPH is suitable for producing PET plastic containers and bottles in all shapes.

Specifications:

Clamping System	Number of cavity	cavities	4
	clamping unit	KG	48000
	mold stroke	mm	130
	stretch stroke	mm	340
	Bottom stroke	mm	30
	Cavity pitch	mm	120
	heating pitch	mm	55
	Number of holder	PCS	114
Container	Max.container volume	ltr	2
	Max. neck diameter	mm	38
	Max.prefrom height	mm	140
	Max.container diameter	mm	110
	Max.container height	mm	340
※theoretical output		B.P.H	4000
Electrical System	heating oven	UNITS	4*12
	box*channel	UNITS	4*12
	Number of lamp	pcs	48
	heating power	KW	57.6
	installed power	KW	65
	voltage	Voltage	220v/380V/3
	voltage	Voltage	phase
	operating pressure	kg/cm²	7
Air System	blowing pressure	mpa	3.5
	high pressure air consuming	L/min	4200
	power	KW	80
	temperature	°C	10-15
Chiller System	pressure	Mpa	0.4
	flow rate	L/min	80
	heating power	HP	5
Machine	machine dimension	M	4.82.22.2
Machine	machine weight	KG	6000

Competitive Advantage:

*Reasonable design, full automaticlly control, save power and labor.
*Feeding system carries the preforms by robot arms automatically.
*Infrared oven adopts the quartz lamp to heat the PET tube.
*Fully automatic process with low investment, high efficiency,quick and safe operation, easy for maintenance.
*We have perfect service after sales .
*Adopting high quality components.

StretHigh Quality Full Automatic 4000BPH PET Bottle Injection Moulding Machine Hot Sale

Download for more details:

Full Automatic Bottle blowing machine.pdf
