5 Gallon Washing Capping Barrel Filling Machine 100 BPH Jar Filling Machinery

5 Gallon Washing Capping Barrel Filling Machine 100 BPH Jar Filling Machinery

Download for more details:

900BPH Barrel Filling Line.pdf

Quick Detail:

1. Name: Barrel Filling Machine
2. Driven Type: Electric
3. Voltage: 110/220/380V
4. Power: 4.8KW
5. Place of Origin: Jiangsu, China (Mainland)
6. Brand Name: Renda
7. Dimension(L*W*H): 3550*1200*1800mm
8. Weight:4000kg
9. Certification: CE,ISO
10. Processing: bottle packing machine
11. Suitable Bottle:5 gallon
12. Material: stainless steel
13. Warranty: 1 year
14. After-sales Service Provided: Engineers available to service machinery overseas

Description:

1.This Barreled Water Filling machine specially produce 3-5 gallons barreled drinking water,

2.those types(barrels/hour)are: 120 type, 300 type, 450 type, 600 type, 900 type, 1200 type.

3.It integrates bottle washer, filler and sealer into one unit.

4.In order to achieve the purpose washing and sterilizing washing machine use multi-washing liquid spray and-thimerosal soray, this merosal can be used circularly.

5.The sealer can seal barrel caps automatically.

6.This line equips with water spraying device in order to ensure those caps sterile and clean, also this line can automatically carry out barrel, washing, sterilizing, filling, capping, counting and products discharging,with complete function, modem desugn and high degree of automation

7.it is a new kind of barreled water auto-producing line, which intgrates mechanism, electricity and pneumatics technologies together.

Applications:

5 Gallon Washing Capping Barrel Filling Machine 100 BPH Jar Filling Machinery

Specifications:

Competitive Advantage:

1. Each water filling machine element tha contacts with the liquid is made of high quality Stainless steel 304, if needed,

SS 316 is also available.

2. The water filling machine adopts bottle neck holding transmission technology to realize fully automatic rinsing, filling and capping.

3. Most elements of the electrical system use famous international brand, such as Mitsubish, Omron brand.

4. The water filling machine obtain the advantages of good abrasive resistance,high stability,low failure rate, etc. The

quality of the equipments reaches the international advanced level.

5. Advanced technologies, human-machine interface touch screen and PLC program control are adopted in this machine.

6. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.

7. Easy to operate, save the cost of workers.
