Automated Water Barrel Filling Machine / 5 Gallon Bottle Filling Machine Electric Driven
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Automated Water Filling Machine | Driven Type: | Electric |
|---|---|---|---|
| Material: | Stainless Steel | Power: | 8.5KW |
| Processing: | Bottle Packing Machine | Product Name: | Barrelled Water Filling Machine / 5 Gallon Bottle Filling Machine/ Filling Plant |
| Warranty: | 1 Year | Name: | Barrel Filling Machine |
| High Light: | water filling machine,automatic bottle filling machine |
||
Automated Water Barrel Filling Machine / 5 Gallon Bottle Filling Machine Electric Driven
Download for more details:
900BPH Barrel Filling Line.pdf
Quick Detail:
Name: Barrel Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 8.5KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H):2200*1860*2700mm
- Weight:7500kg
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle:5 gallon
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
1) The Fully Automatic Barrel Water 5 gallon FillingMachine/Line combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine.
Applications:
Barrelled Water Filling Machine / 5 Gallon Bottle Filling Machine/ Filling Plant
Specifications:
| Model | QGF-100 | QGF-300 | QGF-450 | QGF-600 | QGF-900 |
| Filling heads | 1 | 2 | 3 | 4 | 6 |
| Volume(L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| Capacity(b/h) | 100 | 300 | 450 | 600 | 900 |
| Gas consumption (m3/min) | 0.37 | 0.6 | 0.8 | 1 | 1.5 |
| Moto power (kw) | 1.38 | 3.8 | 5.6 | 7.5 | 9.75 |
| Weight(kg) | 680 | 1500 | 2100 | 3000 | 3500 |
| Size(W*L*H)(m) | 0.5*4.0*1.5 | 0.9*4.0*1.5 | 1.3*4.0*1.5 | 1.8*4.0*1.5 |
2.4*4.0*1.5 |
Competitive Advantage:
1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine
Automated Water Barrel Filling Machine / 5 Gallon Bottle Filling Machine Electric Driven
