Easy Operation 3 - 5 Gallon Barrel Filling Machine With Water Spraying Device

Large Image : Easy Operation 3 - 5 Gallon Barrel Filling Machine With Water Spraying Device Get Best Price

Product Details:

Place of Origin:	Zhangjiagang China
Brand Name:	Renda
Certification:	ISO,CE
Model Number:	QGF-100

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiabled
Packaging Details:	Wooden case
Delivery Time:	20 days
Payment Terms:	T/T, L/C
Supply Ability:	30 pcs/month

Contact Now

Detailed Product Description

Application:	Water Filling Machine	Capacity:	5 Gallon 100BPH
Material:	Stainless Steel	Processing:	Bottle Packing Machine
Certification:	ISO	After-sales Service Provided:	Engineers Available To Service Machinery Overseas
High Light:	water filling machine , automatic bottle filling machine

Easy Operation 3 - 5 Gallon Barrel Filling Machine With Water Spraying Device

Quick Detail:

Name: Barrel Filling Machine
Driven Type: Electric
Voltage: 110/220/380V
Power: 1.75KW
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Weight:800kg
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle:5 gallon
Material: stainless steel
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas

Description:

1,This Barreled Water Production Line specially produce 3-5 gallons barreled drinking water, those types(barrels/hour)are:150 type, 300 type,450 type, 600 type, 750 type,900 type.

2,It is controlled by PLC and made of food grade SUS304.

3,It integrates bottle washer, filler and sealer into one unit.

4,In order to achieve the purpose of washing and sterilizing ,washing machine use multi-washing liquid spray and-thimerosal soray, this merosal can be used circularly.

5,The sealer can seal barrel caps automatically. This line equips with water spraying device in order to ensure those caps sterile and clean, also this line can automatically carry out barrel, washing, sterilizing, filling, capping, counting and products discharging.

Applications:

Customized Factory Price Series 3-5 Gallon Barreled Water Filling Machine With Easy Operation

Specifications:

Model	QGF-100	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200	QGF-2000
Filling heads	1	2	3	4	8	12	16
Volume(L)	18.9	18.9	18.9	18.9	18.9	18.9	18.9
Barrel size(mm)	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490
Capacity(B/n)	100-120	200-240	300-400	600	900	1200	2000
Gas pressure(mpa)	0.4-0.6	0.4-0.6	0.6	0.6	0.6	0.6	0.6
Gas consumption (m³/min)	0.37	0.6	0.6	1.2	2.2	3	4.5
Motor power(Kw)	1.75	3.22	4.8	8.5	8.5	8.5	8.5
Rated voltage(V)	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz
Outline dimension(mm)	3790×650 ×1550	3550×800 ×1800	3550×1200 ×1800	3650×1500 ×1800	2200×1860 ×2700	2560×2350 ×2750	3100×2800 ×2750
Weight(kg)	800	2800	4000	5500	7500	9500	11800

Competitive Advantage:

1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine

Easy Operation 3 - 5 Gallon Barrel Filling Machine With Water Spraying Device

Download for more details:

900BPH Barrel Filling Line.pdf
