10000 BPH Juice Filling Machine Automatic Bottling Juice Equipment For Business 3 In 1
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Fruit Juice|beverage | Capacity: | 10000BPH |
|---|---|---|---|
| Driven Type: | Electric | Power: | 7KW |
| Voltage: | 110V|220V|380V | Processing: | Bottle Packing Machine |
| Material: | SUS 304 316 | ||
| High Light: | automatic bottle filling machine,beverage filling machine |
||
10000 BPH Juice Filling Machine Automatic Bottling Juice Equipment For Business 3 In 1
Name: Juice Filling Machine
Quick Detail:
Driven Type: Electric
Voltage: 110/220/380V
Power: 7KW
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 2360*1770*2400mm
Weight:5T
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle: 0.25-2L
Material: stainless steel
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overse
Description:
1.It is easy to change the shape of bottles, which can be done by changing the thumb wheel without adjusting the height of the machine.
2. Adopting suspensory transmission gear can easily upkeep and be repaired.
3. The machine case and the parts contacting with the materials are made of stainless steel which ensures the good external look and easy washing.
4. It uses frequency changer to control the main machine motor. And it has an output number indicating function which is easy to control the adjustment of the output.
Applications:
Applicable for: fruit juice, tea beverage, functional beverage etc.
Applicable container: various PET bottles with different capacities and shapes
Bottling system: gravity bottling, low vacuum bottling etc.
Production capacity: 8000BPH—10000BPH
Specifications:
| Model | RCGF12/12/6 | RCGFB18/18/6 | RCGF24/24/8 | RCGF32/32/10 | RCGF40/40/12 |
| Number of Rinsing Heads | 12 | 18 | 24 | 32 | 40 |
| Number of Filling Heads | 12 | 18 | 24 | 32 | 40 |
| Number of Capping Heads | 6 | 6 | 8 | 10 | 12 |
| Rated Production Capacity | 5000BPH | 6000BPH | 8000BPH | 12000BPH | 15000BPH |
| Installed Capacity | 3.5 | 4 | 4.8 | 7.6 | 8.3 |
| Overall Size | 2450*1800*2400 | 2650*1900*2400 |
2900*2100 *2400 |
4100*2400 *2400 |
4550*2650 *2400 |
Competitive Advantage:
--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles
--Precise control bottling fluid level, powerfully prevent air bubble
--Sanitary class circulating pipe assures the temperature when bottling
--Capping and clamping technology
Download for more details:
RCGF12-12-6 Juice Washing Filling Machine.pdf
RCGF18-18-6 Juice Washing Filling Capping Machine.pdf
RCGF32-32-10 Juice Washing Filling Capping Machine.pdf
