10000BPH Water Plant Automatic Water Bottle Filling Machine CGF18-18-6 3-IN-1
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Capacity: | 2000ml|8000BPH |
|---|---|---|---|
| Certification: | CE|ISO | Processing: | Bottle Filling And Packing Machine |
| Product Name: | 10000BPH Water Plant Machine Price Water Producing Machine CGF18-18-6 3-IN-1 | Voltage: | 110V|220V|380V |
| Material: | SUS 304/316 | ||
| High Light: | beverage filling machine,water filling machine |
||
10000BPH Water Plant Automatic Water Bottle Filling Machine CGF18-18-6 3-IN-1
Quick Detail:
Driven Type: Electric
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Processing: bottle packing machine
Suitable Bottle: 0.25-2L
Material: stainless steel
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas
no bottle, no filling easy operation and maintenance
Name:Water Bottle Filling Machine
Description:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
Specifications:
Main Technical Specifications | |
Model | CGF18-18-6 |
Production capacity(500ml)(b/h) | 6000-8000b/h |
Way of filling | micro-negative pressure filling |
Filling precision | ±5mm |
Feedback consumption | ≤8% |
Polyester bottle standard(mm) | Bottle Dimaeterƒ50-ƒ92;Height:150-320 |
Suitable cap shape | Plastic cap |
Water pressure of washing bottle(M pa) | 0.2-0.25 |
Water consumption for water bottle(kg/h) | 800 |
Gas source pressure (M Pa) | 0.4 |
Total power(Kw) | 3.2 |
Total Weight(Kg) | 2500 |
Dimension(L*W*Hmm) | 2500*2010*2500 |
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
10000BPH Water Plant Machine Price Water Producing Machine CGF18-18-6 3-IN-1
Download for more details:
6000-8000 Water Bottling Production Line.pdf
