CGF18-18-6 PET Juice / Water Bottle Filling Machine For Beverage Line 3.8KW
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Capacity: | 200ml|2000ml|10000BPH | Driven Type: | Electric |
| Material: | Stainless Steel | Power: | 3.8KW |
| Processing: | Bottle Packing Machine | Product Name: | Water Bottle Filling Machine |
| Voltage: | 110V|220V|380V | Name: | Water Bottle Filling Machine |
| High Light: | automatic bottle filling machine,water filling machine |
||
CGF18-18-6 PET Juice / Water Bottle Filling Machine For Beverage Line 3.8KW
Quick Detail:
- Name:Water Bottle Filling Machine
- Production Name: Water Bottle Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 3.8KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 2900*2450*2400mm
- Weight: 3T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.25-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
Characteristics
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
Specifications:
| Model: | CGF18-18-6 | CGF24-24-8 | CGF32-32-12 | CGF40-40-12 | ||
| capacity :500ml | 5000 | 8000 | 12000 | 16000 | ||
| bottle shape: | roud or square | |||||
| PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | |||||
| cap: | PE srew cap | |||||
| filling precision: | ≤±5mm | |||||
| filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | ||
| rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | ||
| filling volume :(L) | 3.5 | 4 | 6 | 8 | ||
| overall size:(mm) | 2450*1800 *2350 |
2780*2200 *2350 |
3600*2650 *2350 |
3800*2950 *2400 |
||
| weight: (kg) | 3500 | 4500 | 5500 | 6500 | ||
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
CGF18-18-6 Pet Juice / Water Bottle Filling Machine For Beverage Line 3.8KW
Download for more details:
8000-10000Water Bottling Equipment.pdf
