Automatic Drinking Mineral Water Bottle Filling Machine Electric Driven 2000 BPH
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Capacity: | 2000ml|15000BPH | Driven Type: | Electric |
| Material: | Stainless Steel | Voltage: | 110V|220V|380V |
| Power: | 5KW | ||
| High Light: | automatic bottle filling machine,water filling machine |
||
Automatic Drinking Mineral Water Bottle Filling Machine Electric Driven 2000 BPH
Quick Detail:
- Production Name: Water Bottle Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 5KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 3500*2100*2300mm
- Weight: 5T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.25-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
1. The water filling machine is automatic.It’s of many advantages, such as compact structure, perfect control system and easy to be operated. Advanced touch screen and PLC control system makes man-machine communication true.
2. Washing part in the bottle water machine is mainly composed of washing pump, bottle clamps, water distributor, up turn-plate, guide rail, protection cover, spraying device, defrosting tray, rinse water take and rinse water refluxing tank.
3. Filling part in the water filling machine is composed of filling barrel, filling valves (normal temperature and normal pressure filling), filling pump, bottle hanging device / bottle pedestals, elevating device, liquid indicator, pressure gauge, vacuum pump, etc.
4. Capping part in this water filling machine is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.
Techical Parameters:
|
Model(CGF)
|
12-12-6
|
18-18-6
|
24-24-8
|
32-32-8
|
40-40-10
|
50-50-12
|
60-60-15
|
72-72-18
|
|
Capacity(BPH)
|
5000
|
8000
|
12000
|
15000
|
18000
|
22000
|
24000
|
34000
|
|
Rinsing water Pump Power(KW)
|
0.37
|
0.37
|
0.37
|
0.37
|
0.37
|
0.37
|
0.37
|
0.37
|
|
Suitable to Bottle Shape
|
Round and Square container Bottle diameter: 50-120mm Bottle Height: 160-320mm
|
|||||||
|
Drive Motor
|
2.42
|
3.12
|
3.92
|
3.92
|
5.87
|
7.87
|
11.37
|
11.37
|
|
Rinsing Time(s)
|
2.5
|
1.8
|
1.8
|
1.92
|
2
|
2
|
2
|
2
|
|
Drain Time(s)
|
1.4
|
1
|
1
|
1.7
|
1.2
|
1.2
|
1.2
|
1.2
|
|
Water Consumption(T/H)
|
1.5
|
1.5
|
2
|
2
|
3
|
3
|
3
|
3
|
|
(m³/min)
|
0.8
|
0.8
|
0.8
|
0.8
|
0.8
|
0.8
|
0.8
|
0.8
|
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Download for more details:
18000-20000BPH Beverage filling machine.pdf
