Stainless Steel Pet Liquid Filling Line Bottled Spring Water Bottle Filling Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Capacity: | 2000-20000BPH 200ML-20000ML |
|---|---|---|---|
| Material: | Stainless Steel 304/316 | Power: | 4.5KW |
| Processing: | Bottle Filling And Packing Machine | Product Name: | Automatic Small Pet Liquid Filling Line Bottled Spring Water Bottling Machine |
| Voltage: | 110V|380V/customized | Weight: | 2500kg |
| Motor: | Siemens/ABB | ||
| High Light: | automatic bottle filling machine,water filling machine |
||
Stainless Steel Pet Liquid Filling Line Bottled Spring Water Bottle Filling Machine
Quick Detail:
Production Name: Water Bottle Filling Machine
Driven Type: Electric
Voltage: 110/220/380V/Customized
Power: 3.8KW
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 3100*2300*2800mm
Weight: 3.5T
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle: 0.2-2L
Capacity: 2000-20000
Warranty: 1 year
Packing: Wooden Case Packing
After-sales Service Provided: Engineers available to service machinery overseas
Description:
Characteristic of CGF series water bottling machine:
1. The suspending hottle-neckdamping design make the bottle stable during the high-speed moving conditions ,by changing a few parts it can meet the production of different types of bottles easily.
2. The new genernation of SS grabis adopted and the grabs have no contact ,with the area above the bottle's screw thread nozzles in the grad can guarantee the complete wash of the interior of the bottle.
3. The advanced graving filling technology used in this machine makes the filling quick ,steady and accurate.
4. Magnetic gorque is used for screw capping and the power of screw capping can be adjusted steplessly ,capping is realiable and do no harm to the caps
5. Advanced technologies such as human-machine inter face touch-screen and PLC program control are adopted in this machine
6. All parts that have direct contact witht he wafe are made of high quality SS ,the criticed dlectrical components are from famous interantional compies such asMitsubishi ,Omorn to the name a few.
7. Water bottling machine including of bottle rinsing filling capping 3 function in 1 machine.
Technical parameters for water bottling machine:
| Model | CGF12126 | CGF18186 | CGF24248 | CGF323210 |
| Heads of washing,filling,sealing | 12-12-6 | 18-18-6 | 24-24-8 | 32-32-10 |
| Production capacity | 3000-4000BPH | 5000-7000 | 8000-12000 | 12000-15000 |
| Suitable bottle diameter | φ=50-100mm, H=170mm, 330-2500ml | φ=50-100mm, H=170mm, 330-2500ml | φ=50-100mm, H=170mm, 330-2500ml | φ=50-100mm, H=170mm, 330-2500ml |
| Spraying pressure | 0.2-0.25Mpa | 0.2-0.25Mpa | 0.2-0.25Mpa ³ | 0.2-0.25Mpa |
| Motor power | 2.2kw | 2.5kw | 3kw | 5.5kw |
| Stainless steel | SS304 | SS304 | SS304 | SS304 |
| Electric voltage | 380V50Hz | 380V50Hz | 380V50Hz | 380V50Hz |
| PLC | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
| Frequency converters | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
| Touch screen | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
| Circuit contactor | Siemens | Siemens | Siemens | Siemens |
| overall dimension | 2400*1600*2500 | 2500*1800*2500 | 3100*2300*2800 | 3800*2800*2900 |
| Weight | 2500kg | 3500kg | 4500kg | 6500kg |
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Download for more details:
2000-4000 Bottles per hour water filling plant.pdf
6000-8000 Water Bottling Production Line.pdf
8000-10000Water Bottling Equipment.pdf
12000-15000BPH Water Filling Production Line.pdf
18000-20000BPH Beverage filling machine.pdf
Manufacturing more machines:
Beverage filling machine, Water bottling machine, Bottle fillers, Bottling Equipment, Juice filling machine, Liquid filling machines, Bottling Equipment, Carbonated drinks filling machine, Beer filling machine, Can filling machine, Oil filling machine, etc.
