CGF18-18-6 Fully Automatic Water Bottle Filling Machine CE ISO Certificate
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Capacity: | 2000-20000BPH 200ML-20000ML |
|---|---|---|---|
| Material: | Stainless Steel 304/316 | Power: | 4.5KW |
| Product Name: | CGF18-18-6 Automatic Bottle Water Filling Machine CE ISO Certificate | Voltage: | 110V|380V/customized |
| Weight: | 2500kg | Motor: | Siemens/ABB |
| High Light: | automatic bottle filling machine,water filling machine |
||
CGF18-18-6 Automatic Bottle Water Filling Machine CE ISO Certificate
Quick Detail:
Production Name: Water Bottle Filling Machine
Driven Type: Electric
Voltage: 110/220/380V/Customized
Power: 3.8KW
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 3100*2300*2800mm
Weight: 3.5T
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle: 0.2-2L
Capacity: 2000-20000
Warranty: 1 year
Packing: Wooden Case Packing
After-sales Service Provided: Engineers available to service machinery overseas
Description:
Washing, filling and capping 3-in-1 Machine
The three functions of bottle wash, fill and seal are composed in one body of the machine. The whole process is automatic. The machine is used in filling juices, mineral water and purified water in bottles made of polyester and plastics. The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles. The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted.
Technical parameters:
| Model |
Washing heads |
Filling heads |
Capping heads |
Weight |
Overall dimension (mm) |
| CGF12-12-6 | 12 | 12 | 6 | 3200kg | 2500*1880*2300mm |
| CGF18-18-6 | 18 | 18 | 6 | 4500kg | 2800*2150*2300mm |
| CGF24-24-8 | 24 | 24 | 8 | 6500kg | 3100*2450*2300mm |
| CGF32-32-10 | 32 | 32 | 10 | 7500kg | 3680*2800*2500mm |
| CGF40-40-12 | 40 | 40 | 12 | 8500kg | 4100*2800*2300 mm |
| CGF50-50-12 | 50 | 50 | 12 | 9000kg | 4500*3300*2350 mm |
| You can also customize the size you need | |||||
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Download for more details:
2000-4000 Bottles per hour water filling plant.pdf
6000-8000 Water Bottling Production Line.pdf
8000-10000Water Bottling Equipment.pdf
12000-15000BPH Water Filling Production Line.pdf
18000-20000BPH Beverage filling machine.pdf
Manufacturing more machines:
Beverage filling machine, Water bottling machine, Bottle fillers, Bottling Equipment, Juice filling machine, Liquid filling machines, Bottling Equipment, Carbonated drinks filling machine, Beer filling machine, Can filling machine, Oil filling machine, etc.
CGF18-18-6 Automatic Bottle Water Filling Machine CE ISO Certificate
