3 / 5 Gallon 3 In 1 Monoblock Barrel Filling Machine Rinsing - Filling - Capping
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Water | Capacity: | 3 / 5 Gallon |
|---|---|---|---|
| Material: | Stainless Steel | Power: | 4.8KW |
| Processing: | Bottle Packing Machine | Product Name: | 3/5 Gallon Barrel 3-in-1 Rinsing-Filling-Capping Monobloc Machine 1200BPH |
| Voltage: | 110V|220V|380V | ||
| High Light: | beverage filling machine,water filling machine |
||
3 / 5 Gallon 3 In 1 Monoblock Barrel Filling Machine Rinsing - Filling - Capping
Download for more details:
600BPH Barrel Filling Line.pdf
Quick Detail:
Driven Type: Electric
Voltage: 110/220/380V
Power: 4.8KW
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 3550*1200*1800mm
Weight:4000kg
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle:5 gallon
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas
Name:Barrel Filling Machine
Description:
(1)The machine combines auto washing bottle, filling water, placing cap, pressing cap and products outputting as one unit
(2)The PLC(Programmable Logical Controller) controlling systems, which with Panasonic brand and the Air TAC brand pneumatic elements making the machine working more functionally
(3)The international famous brand electric appliances such as LG, OMRON, making the machine working more safely
(4)The main body of the machine made of stainless steel which is sanitary galss and healthy, with impact construction
(5)The rotary spraying washing system can wash bottles more perectly
(6)Inchmeal filling syetem, adjustable filling time, no water spatter when flushing the bottle
Specifications:
| Model | QGF-150 | QGF-250 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 |
| Filling Heads | 1 | 2 | 3 | 4 | 6 | 8 |
| Volume(L) | 18.9 | |||||
| Barrel Size(mm) | φ 270× 490 | |||||
| capacity(b/h) | 120-150 | 240-300 | 400-450 | 500-600 | 700-800 | 1000-1200 |
| Gas Pressure(Mpa) | 0.4-0.6 | 0.4-0.6 |
0.4-0.6 | 0.6 | 0.6 | 0.6 |
| Gas Consumption(m 3 /min) | 0.37 | 0.6 |
0.8 | 1 | 1.2 | 1.5 |
| Moto Power(kw) | 1.38 | 1.75 | 3.8 | 7.5 | 9 | 13.5 |
| Rated Voltage(V) | 380V/50Hz | |||||
| Weight(kg) | 680 | 1200 | 1600 | 2000 | 3500 | 4500 |
Competitive Advantage:
1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine
3/5 Gallon Barrel 3-in-1 Rinsing-Filling-Capping Monobloc Machine 1200BPH
