Mineral / Pure Water Barrel Filling Machine 110V 380V 220V Liquid Filling Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Automatic Grade: | Automatic | Capacity: | 5 Gallon |
|---|---|---|---|
| Material: | Stainless Steel | Power: | 8.5KW |
| Processing: | Bottle Packing Machine | Product Name: | 3/5gallon Mineral/Pure Water Bottle/Barrel/Jar Water Filling Machine 380V/220V |
| Voltage: | 110V|220V|380V | Name: | Barrel Filling Machine |
| High Light: | beverage filling machine,water filling machine |
||
Mineral / Pure Water Barrel Filling Machine 110V 380V 220V Liquid Filling Machine
Download for more details:
900BPH Barrel Filling Line.pdf
Quick Detail:
- Name:Barrel Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 8.5KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 2560*2350*2750mm
- Weight:9500kg
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle:5 gallon
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
1. Automatic break protection for power leakage and short circuit;
2. Under-pressure protection: When incoming air's pressure is =0.5MPa, the equipment will be automatically stopped;
3. Water-shortage protection: When the level of the water tank is lower than that of the liquid switch, the equipment will be automatically stopped.
Applications:
3/5gallon Mineral/Pure Water Bottle/Barrel/Jar Water Filling Machine 380V/220V
Specifications:
| TYPE | QGF-100 | QGF-240 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 |
| filling heads | 1 | 2 | 3 | 4 | 8 | 8 | 8 |
| barrel size(mm) | Φ276x490 | ||||||
| Capacity(b/h) | 60-100 | 100-240 | 250-300 | 400 | 800 | 800 | 800 |
| gas pressure(MPa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 |
| gas consumption(m3/min) | 0.37 | 0.37 | 0.6 | 0.8 | 1 | 1.5 | 1.8 |
| Motor power kw | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9.75 | 13.5 |
| Rated voltage | 380V/50HZ | ||||||
| Weight (kg) | 680 | 800 | 1500 | 2100 | 3000 | 3500 | 4500 |
Competitive Advantage:
1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine
Mineral / Pure Water Barrel Filling Machine 110V 380V 220V Liquid Filling Machine
