Soft Drink Beverage Carbonated Drink Filling Machine Cola Glass Bottle Washing / Filling / Capping
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Beverage|Coca-Cola | Capacity: | 2000-3000BPH |
|---|---|---|---|
| Driven Type: | Electric | Material: | Stainless Steel |
| Power: | 3.57KW | Processing: | Bottle Packing Machine |
| Product Name: | Carbonated Soft Drink Filling Machine Glass Bottle Carbonated Sparkling Drink Filling Machine | Weight: | 2000kg |
| High Light: | water filling machine,automatic bottle filling machine |
||
Soft Drink Beverage Carbonated Drink Filling Machine Cola Glass Bottle Washing / Filling / Capping
Download for more details:
DCGF12-12-6 Beer Filling Machine.pdf
Quick Detail:
- Driven Type: Electric
- Voltage: 110/220/380V
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.25-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overse
- Name:Carbonated Drinks Filling Machine
Description:
1.The series soft drink filling machine is used in production gas containing water of PET polyester bottle-packing carbonated beverage.
2.Adopting equal pressure filling principle and current spring valves in order to assure beverage quality.
3.It carries out washing bottle, filling and capping on one machine.
4.The magnetic torque is used for screw capping., in order to assure capping quality.
5.The main machine adopts advanced PLC control ,Touch screen and no-bottle, no-cap system.
6.It adopts bottle handing technology to make changing bottle more convenient, faster and easier.
7.The whole machine designing is reasonable, the appearance is beautiful and the maintenance is convenient.
Applications:
Applicable for: Cola, Carbonated beverage etc.
Applicable container: various PET bottles with different capacities and shapes
Production capacity: 1000BPH—3000BPH
Technical Parameters:
| Model | CGFD 8-8-3 |
CGFD 12-12-6 |
CGFD 18-18-6 |
CGFD 24-24-8 |
CGFD 32-32-10 |
CGFD 40-40-10 |
| Rinsing Head No | 8 | 12 | 18 | 24 | 32 | 40 |
| Filling Head No | 8 | 12 | 18 | 24 | 32 | 40 |
| Capping Head No | 3 | 6 | 6 | 8 | 10 | 12/10 |
|
Rated Capacity |
1200-1500BPH | 2500BPH | 3500-4000BPH | 7000-7500BPH | 8000-10000BPH | 10000-12000BPH |
| Overall Size | 2000*1600*2300mm | 2200*1600*2300mm | 2450*1900*2300mm | 2750*2180*2400mm | 4000*2300*2300m | 4550*2650*2300mm |
| Weight | 2T | 2.2T | 3.0T | 4.0T | 8.0T | 12.0T |
|
Power (KW) |
3KW | 3.5kw | 4.0kw | 4.8kw | 7.6kw | 8.3Kw |
Competitive Advantage:
--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles
--Precise control bottling fluid level, powerfully prevent air bubble
--Sanitary class circulating pipe assures the temperature when bottling
--Capping and clamping technology
