Product Details:
Payment & Shipping Terms:
|
Application: | Fruit Juice|beverage | Capacity: | 10000BPH |
---|---|---|---|
Material: | Stainless Steel | Power: | 7KW |
Product Name: | Liquid Bottle Filling Machine|Juice Filling Machine | Voltage: | 110V|220V|380V |
Processing: | Bottle Packing Machine | ||
High Light: | beverage filling machine,automatic bottle filling machine |
Automatic Mineral Water Bottling Machine/Juice Packing Machine/Water Processing Equipment
Quick Detail:
Driven Type: Electric
Voltage: 110/220/380V
Power: 7KW
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 2360*1770*2400mm
Weight:5T
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle: 0.25-2L
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overse
Name: Juice Filling Machine
Description:
Model | CGZ12-12-6 | CGZ18-18-6 | CGZ24-24-8 | CGZ32-32-8 | CGZ40-40-10 |
Washing heads | 12 | 18 | 24 | 32 | 40 |
Filling heads | 12 | 18 | 24 | 32 | 40 |
Capping heads | 6 | 6 | 8 | 8 | 10 |
Capacity(b/h)500ml | 2000-4000 | 5000-6000 | 8000-10000 | 10000-15000 | 16000-20000 |
Power motor(kw) | 2.2 | 3.5 | 4.5 | 5.5 | 5.5 |
Applications:
Applicable for: fruit juice, tea beverage, functional beverage etc.
Applicable container: various PET bottles with different capacities and shapes
Bottling system: gravity bottling, low vacuum bottling etc.
Production capacity: 8000BPH—10000BPH
Specifications:
Model |
Capacity |
Power (kw) |
Dimension (mm) |
Weight (kg) |
RCGF24-24-8 |
8000-10000BPH |
7 |
2360*1770*2400 |
5000 |
Competitive Advantage:
--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles
--Precise control bottling fluid level, powerfully prevent air bubble
--Sanitary class circulating pipe assures the temperature when bottling
--Capping and clamping technology
Automatic Mineral Water Bottling Machine/Juice Packing Machine/Water Processing Equipment
Download for more details:
RCGF18-18-6 Juice Washing Filling Capping Machine.pdf
