High Speed Beverage Bottling Equipment Juice Filling Machine Automatic Capping Top Filling Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Beverage | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Capacity: | 1000-4000BPH | Material: | Stainless Steel |
| Product Name: | High Speed Juice Bottling Equipment Automatic Capping Top Filling Machine Water Bottling Plant | Voltage: | 110V|220V|380V |
| Processing: | Bottle Packing Machine | ||
| High Light: | beverage filling machine,automatic bottle filling machine |
||
High Speed Beverage Bottling Equipment Juice Filling Machine Automatic Capping Top Filling Machine
Quick Detail:
- Driven Type: Electric
- Voltage: 110/220/380V
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.25-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overse
- Name: Juice Filling Machine
Description:
(1) PLC control, only need one worker.
(2) Apply touch screen which shows relevant information for operator to make the operation easy.
(3) Automatically record the working status which can be long-term saved.
(4) Automatic lubrication.
(5) Automatically failure alarm, diagnosing, and solution indicating.
(6) The filling capacity can be adjusted at will.
(7) The capping function is optional.
(8) Can be installed with remote debugging system, which can solve problems for long distance customers.
Applications:
Hot Filling Machine can be used for various PET bottles and glass bottles, it is mainly used for tea, juice, milk, sport beverage containers (including fibre and pulp beverage).
Specifications:
| Model | RCGF8-8-3 | RCGF12-12-6 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-10 | RCGF40-40-10 | RCGF50-50-12 |
| Washing No | 8 | 12 | 18 | 24 | 32 | 40 | 50 |
| Filling No | 8 | 12 | 18 | 24 | 32 | 40 | 50 |
| Capping No | 3 | 6 | 6 | 8 | 10 | 10 | 12 |
| Production capacity(500ml b/h) | 2000 | 4000 | 7000-8000 | 10000-12000 | 12000-15000 | 15000-18000 | 20000-22000 |
| Installed Capacity(kw) | 3 | 3.5 | 4 | 4.8 | 7.6 | 8.3 | 9.6 |
| Overall size | 2250*1800*2400 | 2450*1800*2400 | 2650*1900*2400 | 2900*2100*2400 | 4100*2400*2400 | 4550*2650*2400 |
5450*3210*2400 |
Competitive Advantage:
Neck transferring (neck gripping) method is adopted, which can be used for various bottle types and largely reduce abrasion for bottles；
Stable and unique filling valve design ensures accurately control for the filling level；
Sanitary circulation pipes can meet the demand for backflow of product filling and provide reliable guarantee for product quality；
The grip and capping technology is in the advanced level domestically, by combining process features of various products, the steam sterilization can be used on caps.
