Fully Automatic Juice Filling Machine 0.25L 0.5L 1L 2L Bottle Water Milk Filling 20000/24000BPH
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Fruit Juice|beverage | Warranty: | 1 Year |
|---|---|---|---|
| Material: | Stainless Steel | Processing: | Bottle Packing Machine |
| Driven Type: | Electric | Weight: | 3T |
| High Light: | beverage filling machine,automatic bottle filling machine |
||
Automatic Juice Filling Equipment Juice Packaging Machinery Juicer Machine Water Milk Filling 20000/24000BPH
Quick Detail:
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 9KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 2900*2500*2900mm
- Weight:3T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.25-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overse
- Name:Juice Filling Machine
Description:
1. The main frame machine of juice making machine adopts the automatic control technology of PLC and transducer with high degree of automatization.
2. The dynamical system of juice making machine is connected by transmission shaft with stable performance.
3. The filling principle of micro negative gravity increases the precision.
4. The advanced automatic lubricating system wihch equipped on juice making machine requires no manual effort and increases the life span of the machines.
5. The noise of juice making machine is low and the overall machine is easy to maintain.
Applications:
Applicable for: fruit juice, tea beverage, functional beverage etc.
Applicable container: various PET bottles with different capacities and shapes
Bottling system: gravity bottling, low vacuum bottling etc.
Production capacity: 20000-24000bph
Specifications:
| Model | Washing heads ,filling heads and capping heads | Production capacity(bottles per hour for 500ml) | Applicable bottle specifications (mm) | Main motor power(kw) |
| RCGF12-12-6 | 12,12,6 | 4000BPH |
200ml-2500ml |
1.5 |
| RCGF18-18-6 | 18,18,6 | 5500BPH | 2.2 | |
| RCGF24-24-8 | 24,24,8 | 8000BPH | 2.2 | |
| RCGF32-32-10 | 32,32,10 | 10000BPH | 3 | |
| RCGF40-40-10 | 40,40,10 | 14000BPH | 5.5 | |
| RCGF50-50-12 | 50,50,12 | 17000BPH | 5.5 | |
| RCGF60-60-15 | 60,60,15 | 20000BPH | 7.5 |
Competitive Advantage:
--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles
--Precise control bottling fluid level, powerfully prevent air bubble
--Sanitary class circulating pipe assures the temperature when bottling
--Capping and clamping technology
Automatic Juice Filling Equipment Juice Packaging Machinery Juicer Machine Water Milk Filling 20000/24000BPH
