Plastic Bottle Water Bottle Filling Machine / 3 in 1 Washing Filling Capping Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Capacity: | 2000-20000BPH 200ML-20000ML | Driven Type: | Electric |
| Material: | Stainless Steel | Power: | 4.5KW |
| Processing: | Bottle Filling And Packing Machine | Voltage: | 110V|380V |
| Name: | Water Bottle Filling Machine | ||
| High Light: | automatic bottle filling machine,water filling machine |
||
Plastic Bottle Water Bottle Filling Machine / 3 in 1 Washing Filling Capping Machine
Download:
2000-4000 Bottles per hour water filling plant.pdf
6000-8000 Water Bottling Production Line.pdf
8000-10000Water Bottling Equipment.pdf
12000-15000BPH Water Filling Production Line.pdf
18000-20000BPH Beverage filling machine.pdf
Quick Detail:
- Name:Water Bottle Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V/Customized
- Power: 3.8KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 3100*2300*2800mm
- Weight: 3.5T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.2-2L
- Capacity: 2000-20000
- Material: stainless steel
- Warranty: 1 year
- Packing: Wooden Case Packing
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
1.The material which contact directly with the liquid is the SUS304 (Food grade).The 3-in-1 is mainly used to fill pure water, Mineral water, wine and so on.
2.It adopts bottle-neck hanging technology,not only avoiding second pollution to the bottle neck, but also realizing to fill different specs of bottles in one equipment, which greatly
improved commonality of this equipment.
3.Spring cramps are used in the bottle washing process.The empty bottle can be turned over 180 degree for washing.
4.Adopts Magnetic torque to realize screw capping, it can beadjusted without stepless,the screw capping power will be fixed,caps will not be damaged, and meantime it can get good cap sealing.
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
Automatic Plastic Bottle Water Filling Machine / 3 in 1 Washing Filling Capping Machine
Specifications:
| Modle | CGF12-12-6 | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 | CGF40-40-12 | CGF50-50-15 | |
| production capacity (500)(b/h) | 2000-4000 | 6000-8000 | 10000-12000 | 14000-16000 | 16000-18000 | 2000-24000 | |
| suitable bottle shape | circular or square | ||||||
| bottle diameter (mm ) | Φ50-Φ90 | ||||||
| bottle height (mm) | 150-310 | ||||||
| compressed air pressure (MPa) | 0.3-0.7 | ||||||
| washing medium | asptic water | ||||||
| washing water's presure(MPa) | 0.25 | ||||||
| total power (kw) | 3 | 4.4 | 5.2 | 6.2 | 7.8 | 10 | |
| weight (kg) | 220 | 2500 | 4200 | 6000 | 7000 | 9000 | |
| overall dimensions (mm) | 2080*1560*2130 | 2500*1890*2130 | 2900*2030*2250 | 4160*2690*2250 | 4850*2850*2250 | 4500*3300*2350 | |
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Manufacturing more machines:
Beverage filling machine, Water bottling machine, Bottle fillers, Bottling Equipment, Juice filling machine, Liquid filling machines, Bottling Equipment, Carbonated drinks filling machine, Beer filling machine, Can filling machine, Oil filling machine, etc.
Plastic Bottle Water Bottle Filling Machine / 3 in 1 Washing Filling Capping Machine
Wooden case packing:
