Positioning Precision Water Bottle Filling Machine High Speed ISO Certification

Positioning Precision Water Bottle Filling Machine High Speed ISO Certification

Profile:

8000-10000Water Bottling Equipment.pdf

18000-20000BPH Beverage filling machine.pdf

6000-8000 Water Bottling Production Line.pdf

2000-4000 Bottles per hour water filling plant.pdf

12000-15000BPH Water Filling Production Line.pdf

Quick Detail:

1. Name:Water Bottle Filling Machine
2. Driven Type: Electric
3. Voltage: 110/220/380V
4. Power: 3.8KW
5. Place of Origin: Jiangsu, China (Mainland)
6. Brand Name: Renda
7. Dimension(L*W*H): 2900*2450*2400mm
8. Weight: 3T
9. Certification: CE,ISO
10. Processing: bottle packing machine
11. Suitable Bottle: 0.25-2L
12. Material: stainless steel
13. Warranty: 1 year
14. After-sales Service Provided: Engineers available to service machinery overseas

Positioning Precision Water Bottle Filling Machine High Speed ISO Certification

Description:

- for 200-2000ml bottle filling
- 2000-20000 BPH
- no bottle no filling
- Easy operation and maintenance

Characteristics:

1. The machine concept of the CGF series was specifically designed for bottling in a hygienic environment;

2. Thanks to the free-standing transfer starwheels, there are much less exterior surfaces on the fillers than on conventional systems;

3. This innovative design has also the effect of the machine being very easily accessible for maintenance purposes and that it can be expanded at any time without conversion, for example with an additional cap feeder;

4. The OMRON PLC system offers the ideal solution for conductive non-carbonated fill products, as the fill quantity is measured precisely by an inductive flow meter;

5. All filling process steps can be programmed easily and individually – adjusted to the product to be filled and to the container.

6. With all variants of the CGF series for non-carbonated products, the containers are conveyed through the machine by means of neck-handling. This, as well as fill quantity determination via inductive flow meter (IDM) guarantee high flexibility and short change-over times;

7. Depending on the pitch circle, a central or a tubular ring bowl is employed;

8. Product feed pipes connect the product tank with the filling valves. In each connecting pipe, there is an inductive flow meter which measures the quantity of the product flowing through the pipes via the product’s conductivity;

9. The filling process begins after centring of the container and is effected by the free-jet method;

10. In order to be able to cope with the different bottles and products to be filled, one or two filling speeds are available.

Non-carbonated beverages are filled pressureless in multi-chamber operation;

11. Once the preprogrammed amount of liquid has flown into the container, a flow meter signal will trigger closing of the valve;

12. The fill parameters and programmes are stored in the controller making quick change-overs via touch-screen.

Applications:

Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.

Positioning Precision Water Bottle Filling Machine High Speed ISO Certification

Specifications:

Competitive Advantage:

1. Best price & best quality

2. Custom-made details

3. Delievery in time.

4. Life-time good service.

Manufacturing more machines:

Beverage filling machine, Water bottling machine, Bottle fillers, Bottling Equipment, Juice filling machine, Liquid filling machines, Bottling Equipment, Carbonated drinks filling machine, Beer filling machine, Can filling machine, Oil filling machine, etc.
