20000 BPH 10KW Drink Water Bottling Filling Machine Small Bottle Water Bottle Filling Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Capacity: | 18000-20000BPH | Driven Type: | Electric |
| Processing: | Bottle Filling And Packing Machine | Voltage: | 110V|220V|380V |
| Material: | Stainless Steel | Power: | 8.5KW |
| Name: | Water Bottle Filling Machine | ||
| High Light: | automatic bottle filling machine,water filling machine |
||
20000 BPH 10KW Drink Water Bottling Filling Machine Small Bottle Water Bottle Filling Machine
Download:
18000-20000BPH Beverage filling machine.pdf
Quick Detail:
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 5.5KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 4300*2930*2970mm
- Weight: 8.5T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.25-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
- Name:Water Bottle Filling Machine
Description:
1.The water filling machine is automatic.It’s of many advantages, such as compact structure, perfect control system and easy to be operated. Advanced touch screen and PLC control system makes man-machine communication true.
2. Washing part in the bottle water machine is mainly composed of washing pump, bottle clamps, water distributor, up turn-plate, guide rail, protection cover, spraying device, defrosting tray, rinse water take and rinse water refluxing tank.
3. Filling part in the water filling machine is composed of filling barrel, filling valves (normal temperature and normal pressure filling), filling pump, bottle hanging device / bottle pedestals, elevating device, liquid indicator, pressure gauge, vacuum pump, etc.
4. Capping part in this water filling machine is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.
.
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
Specifications:
| Model | CGF8-8-3 | CGF12-12-6 | CGF18-18-6 | CGF24-24-8 | CGF32-32-10 | CGF40-40-10 | CGF50-50-12 |
| Washing No | 8 | 12 | 18 | 24 | 32 | 40 | 50 |
| Filling No | 8 | 12 | 18 | 24 | 32 | 40 | 50 |
| Capping No | 3 | 6 | 6 | 8 | 10 | 10 | 12 |
|
Production capacity (500ml b/h) |
2000 | 4000 | 7000-8000 | 10000-12000 | 12000-15000 | 15000-18000 | 20000-22000 |
| Installed Capacity(kw) | 3 | 3.5 | 4 | 4.8 | 7.6 | 8.3 | 9.6 |
| Overall size | 2250*1800*2400 | 2450*1800*2400 | 2650*1900*2400 | 2900*2100*2400 | 4100*2400*2400 | 4550*2650*2400 |
5450*3210 *2400 |
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
20000 BPH 10KW Drink Water Bottling Filling Machine Small Bottle Water Filling machine
