Beverage Drinking Water / Mineral Water Bottle Filling Machine 6.68kw 6000 - 8000 BPH 330-2000ml
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Capacity: | 6000-8000BPH | Processing Types: | Beverage |
|---|---|---|---|
| Filling Vol: | 330-2000ml | Voltage: | 380v,220v |
| Power: | 6.68kw | Material: | SUS 304 316 |
| Certification: | ISO Certification | ||
| High Light: | water filling machine,beverage filling machine |
||
Beverage Drinking Water / Mineral Water Bottle Filling Machine 6.68kw 6000 - 8000 BPH 330-2000ml
Download:
6000-8000 Water Bottling Production Line.pdf
Quick Detail:
- Water Bottle Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 6.68KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 2500*2000*2200mm
- Weight: 3.5T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.33-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
-for 330-2000ml bottle filling
-6000-8000 BPH
-no bottle no filling
-Easy operation and maintenance
(1) This bottling machine is mainly used for washing, filling and capping PET bottle which can fill non- carbonated drinks such as mineral water, pure water, wine and so on.
(2) Bottle washing, filling and capping are achieved in one machine.
(3) The contact time is shorten between material and the outside. And improved the health conditions, production capacity and economic benefits.
(4) CGF series bottling machine adopts hanging type conveying-bottle structure to make changing bottle mold more convenient, faster and more laborsaving.
(5) The main machine adopts advanced PLC control technology. The key electric elements adopt Mitsubishi, Omron, Siemens, etc international famous products.
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
Specifications:
| Model |
CGF12-12-6 |
CGF18-18-6 |
CGF24-24-8 |
CGF32-32-10 |
CGF40-40-12 |
CGF50-50-15 |
| Washing No | 12 | 18 | 24 | 32 | 40 | 50 |
| Filling No | 12 | 18 | 24 | 32 | 40 | 50 |
| Capping No | 6 | 6 | 8 | 10 | 12 | 15 |
| Production Capacity(500ml) | 4000BPH | 6000BPH |
10000 BPH |
12000 BPH |
16000 BPH |
24000 BPH |
| Install Capacity(KW) | 3.5 | 4 | 4.8 | 7.6 | 8.3 | 9.6 |
| Total weight(kg) | 2500 | 3500 | 5500 | 8000 | 10000 | 12000 |
| Overall size | 2450*1800*2400 | 2650*1900*2400 | 2900*2100*2400 | 4100*2400*2400 | 4550*2650*2400 |
5450*3210*2400 |
Beverage Drinking Water / Mineral Water Bottle Filling Machine 6.68kw 6000 - 8000 BPH 330-2000ml
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Beverage Drinking Water / Mineral Water Bottle Filling Machine 6.68kw 6000 - 8000 BPH 330-2000ml
