380V Plastic Bottle Blowing Machine High Automatization Low Consumption

Large Image : 380V Plastic Bottle Blowing Machine High Automatization Low Consumption Get Best Price

Product Details:

Place of Origin:	Zhangjiagang China
Brand Name:	Renda
Certification:	ISO,CE
Model Number:	CM-A4

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiabled
Packaging Details:	Wooden case
Delivery Time:	30 days
Payment Terms:	T/T, L/C
Supply Ability:	30 pcs/month

Contact Now

Detailed Product Description

Features:	Automatic	Total Power:	48KW
Application:	Bottle\|water Bottle	Plastic Processed:	PET\|plastic
Product Name:	4 Cavity Blow Moulding Machines For Sale 380V Plastic Bottle Molding Machine	Voltage:	380V
Material:	Stainless Steel
High Light:	bottle blow molding machine , automatic blow moulding machine

380V Plastic Bottle Blowing Machine High Automatization Low Consumption

Quick Detail:

Condition: New
Application: Bottle
Plastic Processed: PET
Blow Moulding Type: Stretch Blow Moulding
Automatic: Yes
Model Number: CM-A4
Name:Bottle Blowing Machine

Description:

1) High Automatization

2).High Intelligence:The machine can be controlled through touch screen and running status is shown on it.

3).High Quanlity:Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.

4).High Speed:6800BPH(4-cavity)

5).No Contamination:Closed production zone, good self-lubrication system avoid contamination.

6).Low Cost:Low consumption of electricity, air and water.

7).High Transparency: Easy maintenance, absolute safely, visual inspection, low noise.

Applications:

Full Automatic Plastic Bottle Making Machine Price Molding Machine Price Blow Moulding Companies is suitable for producing PET plastic containers and bottles in all shapes.

Specifications:

Technical parameter
TYPE	ITEM	Unit	CM-A2(TWO CAVITY)	CM-A4(FOUR CAVITY)	CM-A6(SIX CAVITY)
Container	Product material	PET	PET	PET	PET
	Container volume	L	0.05-2.0L	0.05-2.0L	0.05-2.0L
	Theoretic output	Psc/hr	1600-2000	3000-4000	4000-5000
	Preform length	MM	50-200	50-200	50-200
	Max height of bottle	MM	320	320	320
Molding	Preform inner diameter	MM	15-60	15-60	15-60
	Bottle diameter	MM	35-110	35-110	35-110
	Max mold thickness	MM	250	250	250
Air compressor	High pressure compressor	Bar/Mpa	1.0/30 × 2sets	1.0/30 × 3sets	1.0/30 × 4sets
	Locking force	KN	170	600	900
	Mold opening stroke	MM	200	200	200
	Low pressure compressor	Bar/Mpa	2.0/30 × 1set	2.0/30 × 1set	2.0/30 × 2sets
	Air dryer	M3/Mpa	2.0/30 × 1set	2.0/30 × 1set	2.0/30 × 1set
Main machine electricity	Power	KW	15	25	30
Main machine electricity	Voltage / frequency	V/Hz	380-110v/60-50hz	380-110v/60-50hz	380-110v/60-50hz
Machine size and weight	Main machine (L × W × H)	M	2.3 × 1.4× 2.0	3.6 × 1.7 × 2.0	5.0 × 1.8 × 2.0
	Main machine weight	T	1.8	2.8	3.8
	Conveyor (L × W × H)	M	1.4 × 1.1 × 1.85	1.4 × 1.1 × 1.85	1.4 × 1.1 × 1.85
	Conveyor weight	T	0.2	0.2	0.2
	High pressure compressor (L × W × H)	M	1.90 × 0.75 × 1.50 × 1set	1.90 × 0.75 × 1.50 × 3sets	1.90 × 0.75 × 1.50 × 4sets
	Low pressure compressor (L × W × H)	M	1.85 × 0.75 × 1.50×1set	1.85 × 0.75 × 1.50×1set	1.85 × 0.75 × 1.50×1set
	air tank (D × H)	M	0.70 × 2.25/3.0	0.70 × 2.25/3.0	0.70 × 2.25/3.0
	Air dryer (L × W × H)	M	0.85 × 0.50 × 0.95	0.85 × 0.50 × 0.95	0.85 × 0.50 × 0.95
	Air filters	Kg	10 × 3pcs	10 × 5pcs	10 × 6pcs

*Reasonable design, full automaticlly control, save power and labor.
*Feeding system carries the preforms by robot arms automatically.
*Infrared oven adopts the quartz lamp to heat the PET tube.
*Fully automatic process with low investment, high efficiency,quick and safe operation, easy for maintenance.
*We have perfect service after sales .
*Adopting high quality components.

4 Cavity Blow Moulding Machines for Sale 380V Plastic Bottle Molding Machine

Download for more details:
Full Automatic Bottle blowing machine.pdf
