Automatic Injection Moulding Machine PET Bottle Blowing Machine 4000 BPH Full Electrical

Large Image : Automatic Injection Moulding Machine PET Bottle Blowing Machine 4000 BPH Full Electrical Get Best Price

Product Details:

Place of Origin:	Zhangjiagang China
Brand Name:	Renda
Certification:	ISO,CE
Model Number:	CM-A4

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiabled
Packaging Details:	Wooden case
Delivery Time:	30 days
Payment Terms:	T/T, L/C
Supply Ability:	30 pcs/month

Contact Now

Detailed Product Description

Features:	Automatic	Application:	Bottle\|water Bottle
Plastic Processed:	PET\|plastic	Product Name:	Automatic Injection Moulding Machine PET Blowing Machine 4000BPH Full Electrical
Voltage:	220V\|380V	Volume:	0.1-2L
Name:	Name:Bottle Blowing Machine	Material:	SUS 304 316
High Light:	bottle blow molding machine , automatic blow moulding machine

Automatic Injection Moulding Machine PET Bottle Blowing Machine 4000 BPH Full Electrical

Quick Detail:

Condition: New
Application: Bottle
Plastic Processed: PET
Blow Moulding Type: Stretch Blow Moulding
Automatic: Yes
Model Number: CM-A4
Name:Bottle Blowing Machine

Description:

1. Large mold volume: 4-cavity can fit up to 2L bottle.

2. High speed: each single cavity can reach to 1200-1400 bph(4 cavity)

3. Simply and flexiable: to blow difference neck is easy and costless with our machines.

4. High standards: FESTO value and SIMENS PLC.

5. Precision: Each hole's tolarance less than 5mm, to gurantee high speed working.

6. Water cooling system: no need extra water chiller

7. Duriable : all the moving parts is using cooper, copper is sofer then steel ,and oil is auto lubricated.

Applications:

Automatic Injection Moulding Machine PET Blowing Machine 4000BPH Full Electrical is suitable for producing PET plastic containers and bottles in all shapes.

Specifications:

Technical parameter
TYPE	ITEM	Unit	CM-A2(TWO CAVITY)	CM-A4(FOUR CAVITY)	CM-A6(SIX CAVITY)
Container	Product material	PET	PET	PET	PET
	Container volume	L	0.05-2.0L	0.05-2.0L	0.05-2.0L
	Theoretic output	Psc/hr	1600-2000	3000-4000	4000-5000
	Preform length	MM	50-200	50-200	50-200
	Max height of bottle	MM	320	320	320
Molding	Preform inner diameter	MM	15-60	15-60	15-60
	Bottle diameter	MM	35-110	35-110	35-110
	Max mold thickness	MM	250	250	250
Air compressor	High pressure compressor	Bar/Mpa	1.0/30 × 2sets	1.0/30 × 3sets	1.0/30 × 4sets
	Locking force	KN	170	600	900
	Mold opening stroke	MM	200	200	200
	Low pressure compressor	Bar/Mpa	2.0/30 × 1set	2.0/30 × 1set	2.0/30 × 2sets
	Air dryer	M3/Mpa	2.0/30 × 1set	2.0/30 × 1set	2.0/30 × 1set
Main machine electricity	Power	KW	15	25	30
Main machine electricity	Voltage / frequency	V/Hz	380-110v/60-50hz	380-110v/60-50hz	380-110v/60-50hz
Machine size and weight	Main machine (L × W × H)	M	2.3 × 1.4× 2.0	3.6 × 1.7 × 2.0	5.0 × 1.8 × 2.0
	Main machine weight	T	1.8	2.8	3.8
	Conveyor (L × W × H)	M	1.4 × 1.1 × 1.85	1.4 × 1.1 × 1.85	1.4 × 1.1 × 1.85
	Conveyor weight	T	0.2	0.2	0.2
	High pressure compressor (L × W × H)	M	1.90 × 0.75 × 1.50 × 1set	1.90 × 0.75 × 1.50 × 3sets	1.90 × 0.75 × 1.50 × 4sets
	Low pressure compressor (L × W × H)	M	1.85 × 0.75 × 1.50×1set	1.85 × 0.75 × 1.50×1set	1.85 × 0.75 × 1.50×1set
	air tank (D × H)	M	0.70 × 2.25/3.0	0.70 × 2.25/3.0	0.70 × 2.25/3.0
	Air dryer (L × W × H)	M	0.85 × 0.50 × 0.95	0.85 × 0.50 × 0.95	0.85 × 0.50 × 0.95
	Air filters	Kg	10 × 3pcs	10 × 5pcs	10 × 6pcs

Competitive Advantage:

*Reasonable design, full automaticlly control, save power and labor.
*Feeding system carries the preforms by robot arms automatically.
*Infrared oven adopts the quartz lamp to heat the PET tube.
*Fully automatic process with low investment, high efficiency,quick and safe operation, easy for maintenance.
*We have perfect service after sales .
*Adopting high quality components.

Automatic Injection Moulding Machine PET Bottle Blowing Machine 4000 BPH Full Electrical

Download for more details:

Full Automatic Bottle blowing machine.pdf
