Automatic Aluminum Can Filling Machine Sealing Can Packaging Production Line
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Drink|tea|Coca Cola|Water|soda Water | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Driven Type: | Electric | Material: | Stainless Steel |
| Processing: | Bottle Packing Machine | Suitable Bottle: | Iron Can |
| Name: | Can Filling Machine | ||
| High Light: | water filling machine,beverage filling machine |
||
Automatic Aluminum Can Filling Machine Sealing Can Packaging Production Line
Quick Detail:
- Name:Can Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 1.67KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): null
- Weight:1900kg
- Certification: CE,ISO
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overse
Description:
Automatic Aluminum Can Filling Machine Sealing Can Packaging Production Line
1. The Automatic can filling machine on the basis of reference of similar products abroad were improved design, and adds some additional functionality.
2. The product in the use of operation, accuracy error, adjust the machine, cleaning equipment, maintenance etc. more easy and convenient.
3. The machine is compact and reasonable in design, simple and beautiful appearance, easy to adjust filling volume.
4. The machine with 6 filling heads.
5. Using the German FESTO, Taiwan AIRTAC gas dynamic components and Taiwan's Delta electronic components, stable performance.
6. Material contact parts are used 304L stainless steel materials.
7. Filling machine by South Korea light eye device. Bay inverter and French electrical components.
8. Convenient adjustment, bottle filling, filling volume is accurate and with counting function.
9. The anti leakage and wire drawing filling bulkhead, anti high foam products filling lifting system to ensure bottle positioning of the positioning system, and a liquid level control system.
Applications:
This Pop Can filling machine production line is suitable for the production of all kinds of drinks contained in three piece can, such as cola, aerated water, ice tea, etc
Specifications:
Model | QSG-16 | GFP-12(GFP-16/24/32) | FBZ-1 |
Production capacity(can/hour) | 1000-3000 | 1000-8500 | 1000-2500 |
Heads of washing, filling, sealing | 16 | 12 | 1 |
Power(KW) | 0.37 | 0.55 | 0.75 |
Overall dimension(LxWxH)(mm) | 1900x530x1100 | 1000x1000x2100 | 1200x720x1900 |
Weight(kg) | 480 | 800 | 650 |
Competitive Advantage:
Pop Can filling machine
1. Filling all kind of drinks
2. Suitable bottle:iron can
3. Capacity:as required
Automatic Aluminum Can Filling Machine Sealing Can Packaging Production Line
Download for more details:
Juice can washing filling capping machine.pdf
