Application: | Drink|tea|Coca Cola|Water|soda Water | Automatic Grade: | Automatic|automated |
---|---|---|---|
Driven Type: | Electric | Material: | Stainless Steel |
Power: | 1.67KW | Suitable Bottle: | Iron Can |
Voltage: | 110V|220V|380V | ||
High Light: | water filling machine,beverage filling machine |
Carbonated Beverage Packaging Machine Pop Easy Can Filling Machine Automatic Bottle
Quick Detail:
Description:
1. Main components of Aluminum Can/PET Can Filling Machine for juice/beverage/beer
are rinsing, filling-seaming monoblock, tunnel sterilizing machine and conveying system. The key machine is filling and seaming monoblock which synchronizes with filling machine. The liquid level is stable and the oxygen content is decreased.
2. Through a few simple adjustments, it could handle different cans. The special structure sealing roller could be adjusted according to can’s size.
3. As the can is easy to get deformed, soft treatment is needed in the transferring process. The conveying system regulates the transferring speed according to the each machine’s working condition to assure no bottle falling or crashing occurs.
Applications:
This Pop Can filling machine production line is suitable for the production of all kinds of drinks contained in three piece can, such as cola, aerated water, ice tea, etc
Specifications:
Model | SG12-4 | SG18-4 | SG20-4 | SG30-6 |
The number of capping head | 4 | 4 | 4 | 6 |
The number of filling head | 12 | 18 | 20 | 30 |
Production capacity(cans/min) | 150 | 250 | 150 | 250 |
Can Diameter(mm) | 52.5-99 | 52.5-99 | 52.5-99 | 52.5-99 |
Can Height(mm) | 39-160 | 39-160 | 80-160 | 80-160 |
Power(kw) | 5.5 | 5.5 | 5.5 | 7.5 |
Weight(kg) | 3100 | 3800 | 4000 | 6000 |
Dimension(mm) | 2700*1400*1900 | 3050*1750*1900 | 3400*1950*1900 | 3900*2400*1900 |
Competitive Advantage:
Pop Can filling machine
1.Filling all kind of drinks
2.Suitable bottle:iron can
3.Capacity:as required
Carbonated Beverages Bottling Pop Easy Can Plastic Can Packing Machine
