Stainless Steel Red Wine Filling Machine Bottling , Electric Wine Filler Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Wine|Beer|Red Wine|Water | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Driven Type: | Electric | Material: | Stainless Steel |
| Processing: | Bottle Packing Machine | Suitable Bottle: | Glass Bottle |
| Voltage: | 110V|220V|380V | Name: | Wine Filling Machine |
| High Light: | water filling machine,automatic bottle filling machine |
||
Stainless Steel Red Wine Filling Machine Bottling , Electric Wine Filler Machine
Quick Detail:
- Name:Wine Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Certification: CE,ISO
- Material: stainless steel
- Processing: bottle packing machine
- Suitable Bottle:Glass Bottle
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
1.The three functions of bottle washing, filling and capping are composed in one body of the machine.
2. It is automatic in total process and suitable for PET bottled juice tea drink which can resistant high temperature.
3. It also can be used for mineral water, pure water and many other no gas containing drinks.
4. It makes by high quality SUS304 and key parts are precision machined by NC tool.
5. The total machine adopts advanced photoelectric detection technology to detect each part's operation status, no bottle no filling, no bottle no capping, automatic easy operation.
6. Using the wind sent access, with clamp hanging the bottle neck which can keep the bottle shape high-speed.
7. Host adopts advanced PLC automatic control technology, the key electrical components from famous company such as Japan Mitsubishi, France Schneider, Omron.
Applications:
The CGFD series filling machine is specialized in beer filling.
Specifications:
| MODEL | RCGF12-12-6 | RCGF18-18-6 | RCGF24-24-8 | RCGF32-32-10 | RCGF40-40-12 | RCGF50-50-15 |
| PRODUCTION CAPACITY(500ML BPH) | 2000-2400 | 4000-6000 | 6000-10000 | 10000-15000 | 15000-20000 | 20000-24000 |
| FILLING PRECISION | LIQUID LEVEL±2MM | |||||
| BOTTLE SIZE(MM) | DIAMETER50-100 HEIGHT 150-310 | |||||
| CAP SHAPE | PLASTIC SCREW CAP | |||||
| WASHING WATER PRESSURE(MPA) | 0.2-0.25 | |||||
| GAS CONSUMPTION(M3/MIN) | 0.1 | 0.1 | 0.4 | 0.5 | 0.5 | 0.6 |
| POWER(KW) | 3 | 4.4 | 5.2 | 6.2 | 7.8 | 10 |
| WEIGHT(KG) | 2000 | 2800 | 4500 | 6000 | 7000 | 9500 |
| DIMENSIONS(L*W*H MM) | 2080*1560*2130 | 2360*1830*2250 | 2900*2200*2250 | 3880*2200*2250 | 3700*3000*2350 |
4500*3500*2400
|
Download for more details:
DCGF40-40-10 Washing Filling Capping 3-in-1 Machine.pdf
