Automatic Beer Filling Machine Bottle With Washing / Filling / Capping Function
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Beer/carbonated Beer | Material: | Stainless Steel |
|---|---|---|---|
| Processing: | Bottle Packing Machine | Product Name: | Automatic Beer Alcohol Making Machine Beer Filler Wine Bottle Filler Machine |
| Suitable Bottle: | Glass Bottle | Voltage: | 110V|220V|380V |
| Capacity: | 1000BPH-10000BPH | ||
| High Light: | beer bottle filler machine,wine bottle filler machine |
||
Automatic Beer Filling Machine Bottle With Washing / Filling / Capping Function
Quick Detail:
Driven Type: Electric
Voltage: 110/220/380V
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Certification: CE,ISO
Material: stainless steel
Processing: bottle packing machine
Suitable Bottle:Glass Bottle/cans
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas
Name: Beer Filling Machine
Description:
1. The washing, filling and capping 3 kinds of jobs will be finished just by this one machine.
2. It is very convenient to change diverse sizes of bottles by means of advanced bottle conveying technology--bottleneck clamping and bottle suspending technology.
3. Advanced programmable PLC is equipped to control the main machine.
4. Main electronic components are all from famous international enterprises, like Siemens or Mitsubishi.
5. All spare parts that may touch with water are made from high-quality stainless steel.
Applications:
The CGFD series filling machine is specialized in beer filling.
Specifications:
| Model |
BGF 12-12-6 |
BGF 18-18-6 |
BGF 24-24-8 |
BGF 32-32-10 |
BGF 40-40-12 |
BGF 50-50-15 |
BGF 60-60-15 |
BGF 70-70-18 |
| Rinsing heads | 12 | 18 | 24 | 32 | 40 | 50 | 60 | 70 |
| Filling heads | 12 | 18 | 24 | 32 | 40 | 50 | 60 | 70 |
| Capping heads | 6 | 6 | 8 | 10 | 12 | 15 | 15 | 18 |
| Suitable bottle size | H:170-320mm Diaφ:50-100mm | |||||||
| Cleaning pressure(MPa) | 0.25-0.3 | |||||||
| Capacity(B/H) | 2000 | 3500 | 6000 | 9000 | 11000 | 18000 | 22000 | 25000 |
| Power(KW) | 2.2 | 3.5 | 3.8 | 5.5 | 7.5 | 10 | 13 | 15 |
| Dimension(mm) |
2100* 1800* 2700 |
2600*
2100* 2700 |
3200*
2300* 2700 |
4200*
2600* 2700 |
4800*
2800* 2700 |
5700*
3600* 2700 |
6000*
4200* 2700 |
6500*
4500* 2700 |
| Weight(KG) | 2300 | 3500 | 4600 | 6500 | 8500 | 10000 | 11000 | 13000 |
Automatic Beer Alcohol Making Machine Beer Filler Wine Bottle Filler Machine
