Customized 150BPH Barrel Filling Machine / Packaging Machine Water Bottling Machines
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Water | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Capacity: | 5 Gallon 100BPH | Driven Type: | Electric |
| Material: | Stainless Steel | Power: | 3.5KW |
| Voltage: | 110V|220V|380V | ||
| High Light: | beverage filling machine,water filling machine |
||
Customized 150BPH Barrel Filling Machine and Packaging Machine Water Bottling Machines
Quick Detail:
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 1.75KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Weight:800kg
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle:5 gallon
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
- Name:Barrel Filling Machine
Description:
1. The 5 Gallon Filling Machineis composed of barrel washer, barrel filling machine and barrel sealer into one unit.
2. Especially for filling drinking water of 3 and 5 gallons. It is an idea filling line to produce mineral water, distilled water and purified water.
3. The whole line is made of superior stainless steel, anticorrosive and easy to clean.
4. Only two operators are needed for a line, which is wholly automatic barreled
5. Full-auto or semi-auto barrel de-capper, full-auto leakage inspection, full-auto barrel outside brusher, full-auto barrel loading machine,steam shrinking film machine and coding system can be choose depends on what customer's need.
Applications:
Customized 150BPH Barrel Filling and Packaging Machine Water Bottling Machines
Specifications:
|
Model |
QGF-100 |
QGF-300 |
QGF-450 |
QGF-600 |
QGF-900 |
QGF-1200 |
QGF-2000 |
|
Filling heads |
1 |
2 |
3 |
4 |
8 |
12 |
16 |
|
Volume(L) |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
18.9 |
|
Barrel size(mm) |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
φ270×490 |
|
Capacity(B/n) |
100-120 |
200-240 |
300-400 |
600 |
900 |
1200 |
2000 |
|
Gas pressure(mpa) |
0.4-0.6 |
0.4-0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
0.6 |
|
Gas consumption |
0.37 |
0.6 |
0.6 |
1.2 |
2.2 |
3 |
4.5 |
|
Motor power(Kw) |
1.75 |
3.22 |
4.8 |
8.5 |
8.5 |
8.5 |
8.5 |
|
Rated voltage(V) |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
380V/50Hz |
|
Outline dimension(mm) |
3790×650 |
3550×800 |
3550×1200 |
3650×1500 |
2200×1860 |
2560×2350 |
3100×2800 |
|
Weight(kg) |
800 |
2800 |
4000 |
5500 |
7500 |
9500 |
11800 |
Competitive Advantage:
1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine
Customized 150BPH Barrel Filling and Packaging Machine Water Bottling Machines
