Jar Water Barrel Filling Machine 3 / 5 Gallon Bottle Washing / Filling / Capping

Large Image : Jar Water Barrel Filling Machine 3 / 5 Gallon Bottle Washing / Filling / Capping Get Best Price

Product Details:

Place of Origin:	Zhangjiagang China
Brand Name:	Renda
Certification:	ISO,CE
Model Number:	QGF-1200

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiabled
Packaging Details:	Wooden case
Delivery Time:	20 days
Payment Terms:	T/T, L/C
Supply Ability:	30 pcs/month

Contact Now

Detailed Product Description

Application:	Water	Automatic Grade:	Automatic\|automated
Capacity:	5 Gallon	Driven Type:	Electric
Power:	8.5KW	Voltage:	110V\|220V\|380V
Material:	SUS 304 316
High Light:	beverage filling machine , water filling machine

Jar Water Barrel Filling Machine 3 / 5 Gallon Bottle Washing / Filling / Capping

Quick Detail:

Name:Barrel Filling Machine
Driven Type: Electric
Voltage: 110/220/380V
Power: 8.5KW
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 2560*2350*2750mm
Weight:9500kg
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle:5 gallon
Material: stainless steel
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas

Description:

1. The plant can produce 3-5 Gallon Bottle
2. The plant is highly automatic, you can operate on the touch screen to adjust the machine speed and working.
3. We have different speed plants, commonly, 100BPH, 300BPH, 600BPH, 9,000BPH, 12000BPH..ect.
4. The material is stainless steel 304, food grade much clean and safe.
5. We provide the engineers for customer installation, training in customer's factory.

Applications:

Jar Water Barrel Filling Machine 3 / 5 Gallon Bottle Washing / Filling / Capping

Specifications:

Model	QGF-100	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200	QGF-2000
Filling heads	1	2	3	4	8	12	16
Volume(L)	18.9	18.9	18.9	18.9	18.9	18.9	18.9
Barrel size(mm)	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490	φ270×490
Capacity(B/n)	100-120	200-240	300-400	600	900	1200	2000
Gas pressure(mpa)	0.4-0.6	0.4-0.6	0.6	0.6	0.6	0.6	0.6
Gas consumption (m³/min)	0.37	0.6	0.6	1.2	2.2	3	4.5
Motor power(Kw)	1.75	3.22	4.8	8.5	8.5	8.5	8.5
Rated voltage(V)	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz
Outline dimension(mm)	3790×650 ×1550	3550×800 ×1800	3550×1200 ×1800	3650×1500 ×1800	2200×1860 ×2700	2560×2350 ×2750	3100×2800 ×2750
Weight(kg)	800	2800	4000	5500	7500	9500	11800

Competitive Advantage:

1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine

Jar Water Barrel Filling Machine 3 / 5 Gallon Bottle Washing / Filling / Capping

Download for more details:

100BPH 5 Gallon Water Filling Machine.pdf
