Automatic 3.2KW Water Barrel Filling Machine SUS304 Water Bottle Filler 5 Gallon
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Water | Capacity: | 5 Gallon |
|---|---|---|---|
| Material: | Stainless Steel | Power: | 3.22KW |
| Processing: | Bottle Packing Machine | Product Name: | Automatic Water Bottle Filling Machine SUS304 Water Bottle Filler Water Bottling Plant |
| Voltage: | 110V|220V|380V | ||
| High Light: | beverage filling machine,water filling machine |
||
Automatic 3.2KW Water Barrel Filling Machine SUS304 Water Bottle Filler 5 Gallon
Quick Detail:
Name:Barrel Filling Machine
Driven Type: Electric
Voltage: 110/220/380V
Power: 3.22KW
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 3550*800*1800mm
Weight:2800kg
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle:5 gallon
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas
Description:
(1) This filling line specially produces 3&5 gallons barreled drinking water.
(2)This series barreled filling production line integrates bottle washer, filler and sealer into one unit.
(3) In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.
(4) This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.
(5) This line also can automatically carry out bottle washing, sterilizing, filling, capping, counting and products discharging.
(6) It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.
Applications:
Automatic Water Bottle Filling Machine SUS304 Water Bottle Filler Water Bottling Plant
Specifications:
| Model | QGF-100 | QGF-300 | QGF-450 | QGF-600 | QGF-900 |
| Filling heads | 1 | 2 | 3 | 4 | 6 |
| Volume(L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| Capacity(b/h) | 100 | 300 | 450 | 600 | 900 |
| Gas consumption (m3/min) | 0.37 | 0.6 | 0.8 | 1 | 1.5 |
| Moto power (kw) | 1.38 | 3.8 | 5.6 | 7.5 | 9.75 |
| Weight(kg) | 680 | 1500 | 2100 | 3000 | 3500 |
| Size(W*L*H)(m) | 0.5*4.0*1.5 | 0.9*4.0*1.5 | 1.3*4.0*1.5 | 1.8*4.0*1.5 |
2.4*4.0*1.5 |
Competitive Advantage:
1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine
Automatic Water Bottle Filling Machine SUS304 Water Bottle Filler Water Bottling Plant
Download for more details:
100BPH 5 Gallon Water Filling Machine.pdf
