High Efficiency Carbonated Drink Filling Machine Water/Gas/CO2 Washing Filling Capping for Sale
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Beverage|Coca-Cola | Capacity: | 6000BPH |
|---|---|---|---|
| Material: | Stainless Steel | Power: | 5.5kw |
| Processing: | Bottle Packing Machine | Product Name: | High Efficiency Carbonated Water/Gas/CO2 Washing Filling Capping Machine For Sale |
| High Light: | water filling machine,automatic bottle filling machine |
||
High Efficiency Carbonated Drink Filling Machine Water/Gas/CO2 Washing Filling Capping for Sale
Quick Detail:
Name:Carbonated Drink Filling Machine
Driven Type: Electric
Voltage: 110/220/380V
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 2500*1900*2400mm
Weight:5T
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle: 0.25-2L
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overse
Description:
1.Adopts plunger type metering pump filling, high precision; The structure of pump adopts fast
disassembly institutions, easy to clean and disinfect.
2.PLC control system, color touch screen display.
3.This machine has function of no bottle no filling and automatic counting.
4.The filling nozzle was equipped with drip-proof device.
5.When filling liquid, the filling nozzle dive into the bottom of bottle, rising slowly, it can effectively prevent bubbles.
6.Machine body and the parts contacting liquid are made of stainless steel, full compliance with GMP standard.
Applications:
Applicable for: Cola, Carbonated beverage etc.
Applicable container: various PET bottles with different capacities and shapes
Production capacity: 5000BPH—7000BPH
Specifications:
| Technical Data | ||||
| Model | DCGF12-12-6 | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-10 |
| The number of Washing, Filling, Capping | 12-12-6 | 18-18-6 | 24-24-8 | 32-32-10 |
| Applicable bottle specifications (mm) | Φ=50-100 H=170 330-1500ML | Φ50-Φ110 | ||
| Producing capacity: The number of bottle(350ml)/hour |
2000-3000 | 3000-4000 | 6000-8000 | 8000-10000 |
| Filling temperature | 0-5 centi-degree | |||
| Filling type | Press filling type | |||
| Spraying pressure (MPa) | 0.2-0.25 | 0.2-0.25 | ||
| Filling pressure(MPa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | |
| Motor power (kw) | 1.5+0.12+0.45 | 2.2+0.55+0.45 | 3+0.37+0.55 | 7.5 |
| Overall dimension (mm) (L×W×H) | 2300×1600×2500 | 2460×1860×2650 | 3100×2100×2650 | 4350×2880×3200 |
| Weight(kg) | 2500 | 3650 | 4800 | 6000 |
Competitive Advantage:
--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles
--Precise control bottling fluid level, powerfully prevent air bubble
--Sanitary class circulating pipe assures the temperature when bottling
--Capping and clamping technology
High Efficiency Carbonated Water/Gas/CO2 Washing Filling Capping Machine for Sale
Download for more details:
Soft Drinks Filling Machine(Washing, Filling, Capping 3-In-1 Unit)DCGF32-32-10.pdf
