High Speed Soft Drink Carbonated Drink Filling Machine For Coca - Cola Packaging
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Beverage|Coca-Cola | Capacity: | 8000BPH|5000BPH|7000BPH |
|---|---|---|---|
| Material: | Stainless Steel | Processing: | Bottle Packing Machine |
| Product Name: | High Speed Automatic Soft Drink Filling Machine Manufacturer Made In China | Power: | 5KW|6.57KW |
| Weight: | 3500kg | ||
| High Light: | automatic bottle filling machine,beverage filling machine |
||
High Speed Soft Drink Carbonated Drink Filling Machine For Coca - Cola Packaging
Quick Detail:
Name:Carbonated Drink Filling Machine
Driven Type: Electric
Voltage: 110/220/380V
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 3000*2200*2800mm
Weight:3.5T
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle: 0.25-2L
After-sales Service Provided: Engineers available to service machinery overseas
Description:
1. The series carbonated beverage filling machine is used in production gas containing water of PET polyester bottle-packing carbonated beverage.
2. Adopting equal pressure filling principle and current spring valves in order to assure beverage quality.
3. It carries out washing bottle, filling and capping on one machine.
4. The magnetic torque is used for screw capping., in order to assure capping quality.
5. The main machine adopts advanced PLC control ,Touch screen and no-bottle, no-cap system.
6. It adopts bottle handing technology to make changing bottle more convenient, faster and easier.
7. The whole machine designing is reasonable, the appearance is beautiful and the maintenance is convenient.
Applications:
Applicable for: Cola, Carbonated beverage etc.
Applicable container: various PET bottles with different capacities and shapes
Production capacity: 5000BPH—7000BPH
Specifications:
| Model | Number of washing filling and capping | Production capacity Bottle per hour(0.5L) |
Applicable bottle specifications (mm) | Power(kw) | Dimension(mm) |
| DCGF12/12/6 | 12, 12, 6 | 2000-3000 | 0.25L-2L 50-108 mm H=170-340mm |
3.58 | 2100x1400x2500 |
| DCGF18/18/6 | 18, 18, 6 | 4000-6000 | 4.68 | 2460x1720x2650 | |
| DCGF24/24/8 | 24, 24, 8 | 6000-8000 | 6.58 | 3100x2100x2650 | |
| DCGF32/32/8 | 32, 32, 8 | 10000-12000 | 9.68 | 3500x2500x2650 | |
| DCGF40/40/10 | 40, 40, 10 | 13000-15000 | 9.68 | 4600x1800x2650 | |
| DCGF50/50/12 | 50, 50, 12 | 16000-18000 | 10.8 | 5200x4500x3400 | |
| DCGF60/60/15 | 60, 60, 15 | 20000-22000 | 11.28 | 6500x4500x3400 |
Competitive Advantage:
--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles
--Precise control bottling fluid level, powerfully prevent air bubble
--Sanitary class circulating pipe assures the temperature when bottling
--Capping and clamping technology
High Speed Automatic Soft Drink Filling Machine Manufacturer Made In China
Download for more details:
DCGF24-24-8 Carboneted Drinks Washing Filling Capping Machine.pdf
