Electric Driven Carbonated Drink Filling Machine Water Soda Bottle Capping Sealing CO2 SUS304 8000BPH|10000BPH
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Beverage|Coca-Cola | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Capacity: | 8000BPH|10000BPH | Driven Type: | Electric |
| Material: | Stainless Steel | Power: | 9KW |
| Processing: | Bottle Packing Machine | Voltage: | 110V|220V|380V |
| High Light: | automatic bottle filling machine,beverage filling machine |
||
Electric Driven Carbonated Drink Filling Machine Water Soda Bottle Capping Sealing CO2 SUS304 8000BPH|10000BPH
Quick Detail:
- Name: Carbonated Drink Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 9 KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H):3000*2500*2400mm
- Weight:9.8T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.25-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overse
Description:
1.The Small Carbonated Filling Machine washing-filling-capping machine have the three- function of washer, filler and capper in one body, adopting full automation in production process.
2.The Small Carbonated Filling Machine unit makes by high quality stainless steel, key parts are machined on NC tool. The machine unit uses advanced photoelectric detection technology to detect each part's operation condition: No bottle no filling, no bottle no capping. Human- computer interface operational screen make it automation.
3.Therefore, Small Carbonated Filling Machine is ideal equipment for bottling carbonated beverage such as carbonated water, cola, and carbonated wine.
Applications:
Applicable for: Cola, Carbonated beverage etc.
Applicable container: various PET bottles with different capacities and shapes
Production capacity: 8000BPH—10000BPH
Specifications:
| Model: | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-12 | DCGF40-40-12 | |||
| Capacity :500ml | 5000 | 8000 | 12000 | 16000 | |||
| Bottle shape: | roud or square | ||||||
| PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | ||||||
| Cap: | PE srew cap | ||||||
| Filling precision: | ≤±5mm | ||||||
| Filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | |||
| Rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | |||
| Filling volume :(L) | 3.5 | 4 | 6 | 8 | |||
| Overall size:(mm) | 2450*1800 *2350 | 2780*2200 *2350 | 3600*2650 *2350 | 3800*2950 *2400 | |||
| Weight: (kg) | 3500 | 4500 | 5500 | 6500 | |||
Competitive Advantage:
--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles
--Precise control bottling fluid level, powerfully prevent air bubble
--Sanitary class circulating pipe assures the temperature when bottling
--Capping and clamping technology
Machine That Carbonateds Water Soda Bottle Filling Machine With CO2 SUS304
Download for more details:
DCGF40-40-10 Washing Filling Capping 3-in-1 Machine.pdf
