Electric Automatic Liquid Filler Equipment Water Bottle Filling Machine CE ISO Industrial 2000-20000BPH 200ML-20000ML
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Automatic Grade: | Automatic|Automated |
|---|---|---|---|
| Capacity: | 2000-20000BPH 200ML-20000ML | Driven Type: | Electric |
| Material: | Stainless Steel | Power: | 4.5KW |
| Processing: | Bottle Filling And Packing Machine | Voltage: | 110V|380V/Customized |
| Name: | Water Bottle Filling Machine | ||
| High Light: | beverage filling machine,automatic bottle filling machine |
||
Electric Automatic Liquid Filler Equipment Water Bottle Filling Machine CE ISO Industrial 2000-20000BPH 200ML-20000ML
Quick Detail:
- Name:Water Bottle Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V/Customized
- Power: 3.8KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 3100*2300*2800mm
- Weight: 3.5T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.2-2L
- Capacity: 2000-20000BPH
- Material: stainless steel
- Warranty: 1 year
- Packing: Wooden Case Packing
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
1. The equipment is used in production of bottled non-carbonated drink of fruit juice, fruit wine, mineral water and pure water.
2. Rinsing, filling and capping are integrated in one machine.
3. The liquid filling technology of gravity which learned from latest technology from Japan and Germany is used in the design.
4. The filling is fast.
5. The fluid control is stability.
6. There is non-drip phenomenon.
7. Spring cramps are used in the bottle rinsing process. The empty bottles can be turned over 180° Along the conveying rail.
8. Rinsing the bottles inside and outside. The efficiency of bottle rinsing is high.
9. The magnetic torque is used for screw capping. The power of screw capping can also be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged. The capping is reliable.
10. The whole machine is controlled by PLC with touch-screen as the human-machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle. The machine will be stopped automatically. When bottles are cramped wrongly or when caps are not available.
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
CE ISO Electric Automatic Water Filling Machine Wrapping Machine Water Machine 500ml
Specifications:
| Technical Data | ||||
| Model | CGF12/12/6 | CGF18/18/6 | CGF24/24/8 | CGF32/32/10 |
| The number of Washing, Filling, Capping | 12-12-6 | 18-18-6 | 24-24-8 | 32-32-8 |
| Producing capacity; The number of bottle(600ml)/hour |
2000-4000 | 5000-7000 | 8000-12000 | 12000-15000 |
| Applicable bottle specifications (mm) | φ=50-108 H=170-340 330ml-2.25L | |||
| Pressure (kg/cm2) | 2~3 | |||
| Motor power (kw) | Main motor 1.5kw | Main motor 2.2kw | Main motor 3kw | Main motor 4kw |
| Outside vacuum pump power (kw) | 0.75 | 1.1 | 1.5 | 2.2 |
| Overall dimension (mm) (LxWxH) |
2100x1400x2500 | 2460x1720x2650 | 3100x2100x2650 | 3500x2500x2650 |
| Weight(kg) | 2500 | 3500 | 4200 | 5500 |
| Technical Data | |||
| Model | CGF40/40/10 | CGF48/48/12 | CGF60/60/15 |
| The number of Washing, Filling, Capping | 40-40-10 | 48-48-12 | 60-60-15 |
| Producing capacity: The number of bottle(600ml)/hour |
16000-20000 | 20000-24000 | 25000-30000 |
| Applicable bottle specifications (mm) | φ=50-108 H=170-340 330ml-2.25L | ||
| Pressure (kg/cm2) | 2~3 | ||
| Motor power (kw) | Main motor 7.5kw | Main motor 9.5kw | Main motor 12kw |
| Outside vacuum pump power (kw) | 2.2 | 3 | 4 |
| Overall dimension (mm) (LxWxH) |
4600x1800x2650 | 5200x4500x3400 | 6500x4500x3400 |
| Weight(kg) | 6800 | 7600 | 9800 |
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Download for more details:
2000-4000 Bottles per hour water filling plant.pdf
6000-8000 Water Bottling Production Line.pdf
8000-10000Water Bottling Equipment.pdf
12000-15000BPH Water Filling Production Line.pdf
18000-20000BPH Beverage filling machine.pdf
Manufacturing more machines:
Beverage filling machine, Water bottling machine, Bottle fillers, Bottling Equipment, Juice filling machine, Liquid filling machines, Bottling Equipment, Carbonated drinks filling machine, Beer filling machine, Can filling machine, Oil filling machine, etc.
CE ISO Electric Automatic Water Filling Machine Wrapping Machine Water Machine 500ml
Machine details:
Wooden case packing:
