High Efficiency Drinking Water Bottling Equipment , SUS304 Stainless Steel Liquid Filling Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Product Name: | High Efficiency Drinking Water Bottling Equipment For Sale SUS304 Stainless Steel | Application: | Pure Water|mineral Water|beverage |
|---|---|---|---|
| Voltage: | 110V|220V|380V | Power: | 3.8KW |
| Capacity: | 200ml|2000ml|10000BPH | Certification: | CE|ISO |
| Material: | SUS 304 316 | ||
| High Light: | automatic bottle filling machine,water filling machine |
||
High Efficiency Drinking Water Bottling Equipment , SUS304 Stainless Steel Liquid Filling Machine
Quick Detail:
Driven Type: Electric
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Dimension(L*W*H): 2900*2450*2400mm
Weight: 3T
Processing: bottle packing machine
Suitable Bottle: 0.25-2L
Material: stainless steel
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas
Name: Water Bottle Filling Machine
High Efficiency Drinking Water Bottling Equipment for Sale SUS304 Stainless Steel
Description:
- for 200-2000ml bottle filling
- 2000-20000 BPH
- no bottle no filling
- Easy operation and maintenance
1. The suspending bottle-neck clamping design make the bottle stable during the high speed moving conditions. By changing a few parts, it can meet the need of different types of bottles easily.
2. The new generation of stainless steel grab is adopted and the grabs have no contact with the arew above the bottle's screw thread. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.
3. The advanced gravity filling technology used in this machine makes the filler quick,steady and accurate.
4. Magnetic torque is used for screw capping,and the power of screw capping can be adjusted steplessly. Capping is reliable and do no harm to the caps.
5. Advanced technologies,such as human-machine interface touch-screen and PLC program control are adopted in this machine.
6. All parts that directly contacting with water are made of high stainless steel. The critical electrical components are from famous international companies, such as mitsubishi, omron and other famous brands.
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
High Efficiency Drinking Water Bottling Equipment for Sale SUS304 Stainless Steel
Specifications:
| Model | Capacity |
Power (kw) |
Dimension (mm) |
Weight (kg) |
| CGF12-12-6 | 2000-4000BPH | 1.5 | 2360*1770*2400 | 2000 |
| Model | Capacity |
Power (kw) |
Dimension (mm) |
Weight (kg) |
| CGF18-18-6 | 6000-8000BPH | 3 | 2500*2000*2200 | 3000 |
| Model | Capacity |
Power (kw) |
Dimension (mm) |
Weight (kg) |
| CGF24-24-8 | 6000-8000BPH | 3 | 2500*2000*2200 | 3000 |
| Model | Capacity |
Power (kw) |
Dimension (mm) |
Weight (kg) |
| CGF32-32-10 | 12000-15000BPH | 5 | 3500*2100*2300 | 5000 |
| Model | Capacity |
Power (kw) |
Dimension (mm) |
Weight (kg) |
| CGF40-40-10 | 18000-20000BPH | 9 | 4960*2280*2580 | 8000 |
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Download more details:
8000-10000Water Bottling Equipment.pdf
12000-15000BPH Water Filling Production Line.pdf
18000-20000BPH Beverage filling machine.pdf
6000-8000 Water Bottling Production Line.pdf
2000-4000 Bottles per hour water filling plant.pdf
Manufacturing more machines:
Beverage filling machine, Water bottling machine, Bottle fillers, Bottling Equipment, Juice filling machine, Liquid filling machines, Bottling Equipment, Carbonated drinks filling machine, Beer filling machine, Can filling machine, Oil filling machine, etc.
High Efficiency Drinking Water Bottling Equipment for Sale SUS304 Stainless Steel
Wooden case packing:
Products Sample:
