Straight Line Water Automatic Water Bottle Filling Machine Liquid Filling Machines
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Pure Water|mineral Water|beverage | Capacity: | 5L/1000BPH |
|---|---|---|---|
| Driven Type: | Electric | Product Name: | Straight Line Water Automatic Water Bottle Filling Machine Liquid Filling Machines |
| Voltage: | 110V|220V|380V | Material: | Stainless Steel SUS304 |
| Power: | 3.8KW | ||
| High Light: | beverage filling machine,water filling machine |
||
Straight Line Water Automatic Water Bottle Filling Machine Liquid Filling Machines
Quick Detail:
Driven Type: Electric
Voltage: 110/220/380V
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Certification: CE,ISO
Processing: bottle packing machine
Suitable Bottle: 5L
Material: stainless steel
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas
Name: Water Bottle Filling Machine
Description:
1,HX-10 automatic rinsing machine by two electric blunt bottle by our constitution is machine design process and technology independent research and development of apply to the VAT before filling automatically disinfection rinse advanced type.
2,The machine uses pneumatic principle to be automatic clip bottle mouth flip 180 ° way, turning 180 ° after washing into transportation to the next procedure. Can be used in Various bottle type, eliminated the wear of the bottle conveying smoothly.
3,The two way flushing process. A for disinfection liquid, to undertake alexipharmic flush, ensure the bottle of bottle health, the washing system with disinfection disinfectant collect recycling equipment, disinfection liquid can be recycled, save the cost. The second way to rinse rinse water, will the bottle of the remainder of the disinfection liquid clean, ensure before filling the clean health.
4,Rack with stainless steel frame, material contact components ones for 304 stainless steel layer.
5,The electric sealed, PLC control system, PLC from Japan Mitsubishi is used, Omron photoelectric switch, induction switch relay components, sets up to touch screen operation panel, AIRTAC pneumatic components.
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
Specifications:
| Name | Data |
| Overall Size L/W/H | 2000×1000×1800(mm) |
| Power | 0.55KW |
| Voltage | AC 4-380V/50HZ |
| Rinsing Water Pressure | 0.25～0.3MPa |
| Rinsing Water Consumption | 1000Kg/h |
| Air Pressure | 0.6 MPa |
| Air Consumption | 600L/min |
| Weight | 1200Kg |
| Temperature | ≤25℃ |
| Type | HY-10 |
| Capacity | 1000per hour |
| Bottle diameter | According to customer’s requirement |
| Bottle Height | According to customer’s requirement |
| Power | 3.55KW(380V,50HZ) |
| Size | 2000*1400*2200(mm) |
| Weight | About1200KG |
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Download for more details:
Straight Liner washing filling capping .pdf
