Stainless Steel Mineral Water Barrel Filling Machine Bottle Packing Line Water Bottle Filler

Stainless Steel Mineral Water Barrel Filling Machine Bottle Packing Line Water Bottle Filler

Quick Detail:

Driven Type: Electric

Voltage: 110/220/380V

Power: 8.5KW

Place of Origin: Jiangsu, China (Mainland)

Brand Name: Renda

Dimension(L*W*H): 3650*1500*1800mm

Weight:5500kg

Certification: CE,ISO

Processing: bottle packing machine

Suitable Bottle:5 gallon

Warranty: 1 year

After-sales Service Provided: Engineers available to service machinery overseas

Name:Barrel Filling Machine

Description:

• This 5 gallon filling machinery specially produces 5 gallons bottled drinking water,whose types(b/h)are:100 type,200type,300type,450 type,600type,900 type,1200type and 2000 type. 5 gallon filling machinery integrates bottle washer,filler andsealer into one unit,in order toachieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and leaching areused in bottle washer,Washing solution can boused circularly.The 5 gallon filling machinery sealer can seal bottle caps automatically.This 5 gallon filling machinery equips with water spraying device tosterilize caps of bottlesin order to ensure those caps are aseptic and healthy,also this 5 gallon filling machinery can automatically carry out bottle feeding washing,sterilizing,filling capping,counting and products discharging.It is a new kind of barreled water auto-producting line,which 5 gallon filling machinery integrates mechanism,electricity and pneumatics technologies together.

Applications:

Bottling Machine for Mineral/Pure Water Barrel Filling Machine Bottle Packing Line

Specifications:

Competitive Advantage:

1. This machine is used to produce 5 gallon drinking water.

2. This machine composed with Rinse, filler and capper.

3. It is the ideal equipment for mineral water, distilled water and pure water producing process.

4. The machine is made of great stainless steel which is corrosion resistant and easy cleaning.

5. All the pneumatic parts are from the famous brand AIRTAC.

6. Both the inner and outer shower nozzle for washing barrel adopts the special technology equipment from American Sprayer Company.

7. The machine works reliably and efficiently based on the compact structure and high automatic technology.

8. It Is a fully automatic barreled water producing equipment combined with machine, electronic and pneumatic components.

9. The main parts of the system are imported. The filling nozzle are imported from American famous brand

• Intelligent management,PLC control
• Electric part from SIEMENS Germany
• Pneumatic parts from AIRTAC Taiwan
• Stainless steel is food grade
• Automatic cap unscrambler
• Automatic protection device
