20000BPH Juice Packaging Machine Carrot Juice Filling Machine Making Machinery Warranty 1 Year

20000BPH Juice Packaging Machine Carrot Juice Filling Machine Making Machinery Warranty 1 Year

Quick Detail:


• Driven Type: Electric
• Voltage: 110/220/380V
• Power: 9KW
• Place of Origin: Jiangsu, China (Mainland)
• Brand Name: Renda
• Dimension(L*W*H): 2900*2500*2900mm
• Weight:9T
• Certification: CE,ISO
• Processing: bottle packing machine
• Suitable Bottle: 0.25-2L
• Material: stainless steel
• Warranty: 1 year
• After-sales Service Provided: Engineers available to service machinery overse
• Name:Juice Filling Machine

Description:


• Automatic Juice Tea Filling Plant(RCGF50-50-12)--- The juice tea filling plant was used for hot filling for green tea, black tea, wulong tea, juice, juice drink, fruit juice, juice beverage,milk, milk drink and so on non-gas liquid. The fruit jucie tea filling plant is combined with bottle rinsing, hot bottling and capping in one body. The whole process is automatic.
• It is suitable for PET bottle and plastic bottle to fill juice, mineral water, pure water, if add temperature control device, even for hot filling.
• The adjustment for bottle type of each unit is fulfilled by turning handle; it is simple, easy and quick. The filling method applies new micro pressure filling so that the filling speed becomes more quick and stable.
• Compared with similar machines, it has higher yield, more benefit. The machine applies advance OMRON programmable controller (PLC) to control machine’s auto-running, the input bottle chain way changes its speed by frequency converter. Cooperate more stable and reliable.


Applications:

Applicable for: fruit juice, tea beverage, functional beverage etc.
Applicable container: various PET bottles with different capacities and shapes
Bottling system: gravity bottling, low vacuum bottling etc.
Production capacity: 20000-24000bph


Specifications:

Competitive Advantage:

--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles
--Precise control bottling fluid level, powerfully prevent air bubble
--Sanitary class circulating pipe assures the temperature when bottling
--Capping and clamping technology

20000BPH Juice Packaging Machine Carrot Juice Making Machinery Warranty 1 Year

Download for more details:

RCGF32-32-10 Juice Washing Filling Capping Machine.pdf
