Full Automatically PET Water Bottle Filling Machine , Mineral Water Liquid Filling Equipment 6000-8000BPH
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Capacity: | 6000-8000BPH | Processing Types: | Pure Water,Mineral Water,Beverage |
|---|---|---|---|
| Filling Vol: | 330-2000ml | Voltage: | 380v,220v |
| Power: | 6.68kw | Material: | SUS.304 |
| Name: | Water Bottle Filling Machine | ||
| High Light: | automatic bottle filling machine,water filling machine |
||
Full Automatically PET Water Bottle Filling Machine , Mineral Water Liquid Filling Equipment 6000-8000BPH
Quick Detail:
- Name:Water Bottle Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Power: 6.68KW
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Dimension(L*W*H): 2500*2000*2200mm
- Weight: 3.5T
- Certification: CE,ISO
- Processing: bottle packing machine
- Suitable Bottle: 0.33-2L
- Material: stainless steel
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
1.All the machine part which contact with liquid is high quality stainless steel 304. The relative fittings are from international famous brand.
The whole machine is controlled by PLC with touch-screen as the human-machine interface.
2.The water filling machine was equipped with suspension type air conveyor
and frequency control of motor speed.
3.These series of machines integrate washing, filling and capping into one unit.
Rinsing: grip the bottle neck, rotate filling plate, inverse bottle;
There are two times of internal and external washing ,
the efficiency of bottle washing is high.
Filling: gravity filling with holding bottle neck;
the special backflow type of the filling valve can avoid leakage
after filling and also control liquid level accurately.
Capping: magnetic torque bottle holding type can minimize the cap damage rate
and make the capping performance the best.
4.This machine owns the reasonable, stable and safe design.
Under the condition that the bottle neck size is the same,
only the output star wheel needs to be changed
if bottles are different. It improves the efficiency a lot.
Description:
-for 330-2000ml bottle filling
-6000-8000 BPH
-no bottle no filling
-Easy operation and maintenance
Applications:
Water filling machine is used to fill pure water, mineral water and other non-carbonated beverage.
Specifications:
|
Model |
Capacity |
Power (kw) |
Dimension (mm) |
Weight (kg) |
|
CGF18-18-6 |
6000-8000BPH |
6.68 |
2500*2000*2200 |
3500 |
Competitive Advantage:
1. Best price & best quality
2. Custom-made details
3. Delievery in time.
4. Life-time good service.
Full Automatically PET Water Bottle Filling Machine , Mineral Water Liquid Filling Equipment 6000-8000BPH
Download for more details:
6000-8000 Water Bottling Production Line.pdf
