Three in One Liquid Filling Machine , Carbonated Drink Filling Machine Plant for Gas beverage 110V

Three in One Liquid Filling Machine , Carbonated Drink Filling Machine Plant for Gas beverage 110V​

Quick Detail:

Driven Type: Electric

Voltage: 110/220/380V

Power: 3.5KW

Place of Origin: Jiangsu, China (Mainland)

Brand Name: Renda

Dimension(L*W*H): 2360*1770*2400mm

Weight:3.6T

Certification: CE,ISO

Processing: bottle packing machine

Suitable Bottle: 0.25-2L

Warranty: 1 year

After-sales Service Provided: Engineers available to service machinery overse

Name:Carbonated Drink Filling Machine

Description:

1.This kind of  carbonated drink filling machine combines washing,filling and rotary capping functions  in one unit.It is a fully automatic and high efficiency liquid packing equipment.

2. carbonated drink filling machine is suitable for packing beverage containing gas. carbonated drink filling machine 's performance is as following all parts,for instance, filling valve, which directly contact medium are made of stainless steel or harmless material. So it conforms to the requirements of Food sanitation. Sealing parts are made of heat-proofing rubber, in order to meet the technique requirements of users to sterilization at high temperature.

3. carbonated drink filling machine Using programmable controller to realize fully automatic control from bottles entering to finishing packing, Using transducer as speed regulator, so the user can regulate the machine easily to suit different power requirements, Adopting equal pressure filling principle and current spring valves in order to assure beverage quality, Using advanced magnetic coupler to regulate cap-screwing torque, in order to assure capping quality.

Applications:

Applicable for: Cola, Carbonated beverage etc.

Applicable container: various PET bottles with different capacities and shapes

Production capacity: 3000BPH—5000BPH

Specifications:

Competitive Advantage:

--It conveys bottle through clamping the bottle mouth, which is convenient for switching between different capacities of bottles

--Precise control bottling fluid level, powerfully prevent air bubble

--Sanitary class circulating pipe assures the temperature when bottling

--Capping and clamping technology

Three in One Liquid Filling Machine , Carbonated Drink Filling Plant for Gas beverage 110V

Download for more details:

Soft Drinks DCGF18-18-6 Washing Filling Capping 3-in-1 machine.pdf
