Fully Automatic Liquid Bottle Wine Filling Machine in 380V for PET Bottle Glass Bottle
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Wine|Beer | Certification: | CE|ISO |
|---|---|---|---|
| Processing: | Bottle Packing Machine | Product Name: | Fully Automatic Liquid Bottle Filling Machine In 380V For PET Bottle Glass Bottle |
| Suitable Bottle: | Glass Bottle | Voltage: | 110V|220V|380V |
| Material: | SUS 304 316 | ||
| High Light: | beverage filling machine,automatic bottle filling machine |
||
Fully Automatic Liquid Bottle Wine Filling Machine in 380V for PET Bottle Glass Bottle
Quick Detail:
Driven Type: Electric
Voltage: 110/220/380V
Place of Origin: Jiangsu, China (Mainland)
Brand Name: Renda
Material: stainless steel
Processing: bottle packing machine
Suitable Bottle:Glass Bottle
Warranty: 1 year
After-sales Service Provided: Engineers available to service machinery overseas
Name: Wine Filling Machine
Description:
Automatic New Type Beer PET/Glass Bottle Filling Machine for pub brewing 500mL for glass bottle adopts continuous automatic control for liquid level in the filling bowl, double-leader type centering cover, twice vacuumizing, low-temperature equal-pressure filling, automatic concentrated lubrication and the capping heads have been installed with overloading protection device.
The Automatic New Type Beer PET/Glass Bottle Filling Machine for pub brewing 500mL for glass bottle has the function of closeing filling valves when there is broken bottle, and washing away broken bottle. The vent pipe has automatic foam-removing device
The crafty cap-unscrambling and capping design with overloading protection and the function is sufficient. It is controlled by PLC.
Applications:
The CGFD series filling machine is specialized in beer filling.
Specifications:
|
Model |
CGFD 8-8-3 |
CGFD 12-12-6 |
CGFD 18-18-6 |
CGFD 24-24-8 |
CGFD 32-32-10 |
CGFD 40-40-10 |
|
Rinsing Head No |
8 |
12 |
18 |
24 |
32 |
40 |
|
Filling Head No |
8 |
12 |
18 |
24 |
32 |
40 |
|
Capping Head No |
3 |
6 |
6 |
8 |
10 |
12/10 |
|
RatedCapacity |
1200-1500BPH |
2500BPH |
3500-4000BPH |
7000-7500BPH |
8000-10000BPH |
10000-12000BPH |
|
Overall Size |
2000*1600* 2300mm |
2200*1600* 2300mm |
2450*1900* 2300mm |
2750*1180* 2400mm |
4000*2300* 2300mm |
4550*2650* 2300mm |
|
Weight |
2T |
2.2T |
3.0T |
4.0T |
8.0T |
12.0T |
|
Power(KW) |
3KW |
3.5kw |
4.0kw |
4.8kw |
7.6kw |
8.3Kw |
|
Rated Voltage |
380V |
380V |
380V |
380V |
380V |
|
Download for more details:
DCGF12-12-6 Washing,Filling,Capping 3-in-1 Machine.pdf
