Shrink Tunnel L Sealer Beverage Automated Packaging Machines For PET Glass Bottle 110V
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Features: | Automatic | Driven Type: | Electric |
|---|---|---|---|
| Material: | Stainless Steel | Power: | 20KW |
| Suitable Bottle: | Glass Bottle | Voltage: | 110V|380V |
| Name: | Automated Packaging Machines | ||
| High Light: | liquid packing machine,beverage Packaging Machine |
||
Shrink Tunnel L Sealer Beverage Automated Packaging Machines For PET Glass Bottle 110V
Download for more details:
Automatic Shrink Packing Machine.pdf
Quick Detail:
- Driven Type: Electric
- Voltage: 110/220/380V
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Certification: CE,ISO
- Material: stainless steel
- Processing: bottle packing machine
- Suitable Bottle:Glass Bottle
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
- Name: Automated Packaging Machines
Description:
1.MB-6545 is a fully automatic shrink packaging machine including L sealer and shrink tunnel which can feed products, seal and cut film and shrink film bag automatically. It is widely used in food, pharmaceutical, stationary, toy, auto parts, cosmetics, printing, hardware, electrical appliances and other industry.
2. Special durable alloyed sealing knife with anti-stick Teflon coats makes sealing strong and has better performance of heat conduction.
3. Only adjust packing width and height by hand wheels without changing any molds and parts when packing size changes. Packing length can be detected by the sensor automatically.
4. Different products with different sizes can be packed together as promotional package.
5. Adopt Omron brand parts such as temperature controller, timer, relay, switch, and sensor.
6. A pair of photoelectric switch in vertical for thin products.
7. Optional closing conveyor for small products.
8. Optional sensor for transparent products.
Applications:
This type of Shrink packing machine is suit for beverage, drinking water, beer, wine and infusion bottle ect.packaging, which can be packed without tray and with a firm and beautiful appearance.
Specifications:
| Technical Data | MB-6545 |
| Sealing type | L-sealing |
| Power supply | 380V/50-60Hz/3phase |
| Packing capacity | 15 - 35 packs/min |
| L-bar sealing size | 570x480 mm |
| Sealing height | 150 mm |
| Product size | width + height < 400mm, length + height < 480mm |
| Film type | center-folded polyolefin (POF) film |
| Max film size | 530mm (width) x 280mm(outer diameter) |
| Oven size | 1200(L) x 450(W) x 220(H) mm |
| Shrink tunnel conveyor speed | variable, max. 40 m/min |
| Shrink tunnel conveyor | rotating silicon coated rods |
| Power consumption | max. 8.5 kW |
| Working height | 780-850 mm |
| Air pressure | 0.5MPa (5 bar) |
| Sealing knife | Teflon coated alloyed knife with permanently heated bar |
| Main control components | Omron temperature controller, timer, relay and sensor |
| Machine main material | powder coated carbon steel |
| Machine dimension | 1600 x 770 x 1450mm 1600 x 600 x 1260mm |
| Machine weight | 450kgs |
Shrink Tunnel L Sealer Beverage Automated Packaging Machines For PET Glass Bottle
