CE Certificate High Speed Wine Filling Machine Electric Driven 110V / 220V / 380V
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Wine|Beer|Red Wine|Water | Automatic Grade: | Automatic|automated |
|---|---|---|---|
| Driven Type: | Electric | Material: | Stainless Steel |
| Processing: | Bottle Packing Machine | Product Name: | Wine Equipment Supplies Wine Processing Equipment Chinese Suppliers CE Certificate |
| Voltage: | 110V|220V|380V | Name: | Wine Filling Machine |
| High Light: | water filling machine,automatic bottle filling machine |
||
CE Certificate High Speed Wine Filling Machine Electric Driven 110V / 220V / 380V
Quick Detail:
- Name:Wine Filling Machine
- Driven Type: Electric
- Voltage: 110/220/380V
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: Renda
- Certification: CE,ISO
- Material: stainless steel
- Processing: bottle packing machine
- Suitable Bottle:Glass Bottle
- Warranty: 1 year
- After-sales Service Provided: Engineers available to service machinery overseas
Description:
1. The washing, filling and capping 3 kinds of jobs will be finished just by this one machine.
2. It is very convenient to change diverse sizes of bottles by means of advanced bottle conveying technology--bottleneck clamping and bottle suspending technology.
3. Advanced programmable PLC is equipped to control the main machine.
4. Main electronic components are all from famous international enterprises, like Siemens or Mitsubishi.
5. All spare parts that may touch with water are made from high-quality stainless steel.
Applications:
The CGFD series filling machine is specialized in beer filling.
Specifications:
|
Model |
CGFD 8-8-3 |
CGFD 12-12-6 |
CGFD 18-18-6 |
CGFD 24-24-8 |
CGFD 32-32-10 |
CGFD 40-40-10 |
|
Rinsing Head No |
8 |
12 |
18 |
24 |
32 |
40 |
|
Filling Head No |
8 |
12 |
18 |
24 |
32 |
40 |
|
Capping Head No |
3 |
6 |
6 |
8 |
10 |
12/10 |
|
RatedCapacity |
1200-1500BPH |
2500BPH |
3500-4000BPH |
7000-7500BPH |
8000-10000BPH |
10000-12000BPH |
|
Overall Size |
2000*1600* 2300mm |
2200*1600* 2300mm |
2450*1900* 2300mm |
2750*1180* 2400mm |
4000*2300* 2300mm |
4550*2650* 2300mm |
|
Weight |
2T |
2.2T |
3.0T |
4.0T |
8.0T |
12.0T |
|
Power(KW) |
3KW |
3.5kw |
4.0kw |
4.8kw |
7.6kw |
8.3Kw |
|
Rated Voltage |
380V |
380V |
380V |
380V |
380V |
|
Download for more details:
DCGF12-12-6 Washing,Filling,Capping 3-in-1 Machine.pdf
